Zoeller N98 - 1/2 HP Cast Iron Submersible Sump Pump (Non-Automatic)

Zoeller N98 - 1/2 HP Cast Iron Submersible Sump Pump (Non-Automatic)
Our Price
Compare Prices
Shipping Info
Model: N98
(Based on expert analysis, manufacturer ratings and customer reviews)
4.7 out of 54.7 out of 54.7 out of 54.7 out of 54.7 out of 5
Number of Reviews (41)
Write A Review
$248.25
In-Stock
Ships Wednesday, Nov 14th
Free Shipping
In-Stock Free Shipping$248.25Buy Now
In-Stock Free Shipping$248.25Visit Site
$248.25Visit Site

(as of 06:52 CST - Details)Sales Tax Extra $278.15Visit Site
In-Stock
Ships Wednesday, Nov 14th
Free Shipping
Free Shipping
Expedited Shipping
Expedited Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • 41
    Reviews
  • 6
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Primary Sumps Pumps
GPH
4320
Gallons
Switch Type
Style
Primary
GPH
4320 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • ***NON-AUTOMATIC - Requires Float Switch***
  • Submersible Cast Iron Sump Pump
  • Offers years of reliable, trouble-free operation
  • No Sheet Metal Parts To Rust Or Corrode
  • Stainless steel screws, guard, handle, arm and seal assembly
  • Thermally Protected, Permanent Split Capacitor Motor
  • Oil-filled and hermetically sealed to prevent overheating
  • Carbon & Ceramic Shaft Seal
  • Assures maximum protection for extended pump life
  • Powder Coated Epoxy Finish
  • Provides a corrosion resistant exterior
  • Clog-Resistant Design
  • No screen to interfere with flowing debris
  • Capable of passing 1/2" diameter solids
  • Industry Leading Quality Control
  • Entire unit is pressure tested after assembly
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Running Amps
9.4
Thermal Protection
Yes
Power Cord Length
15 Feet
Oil Free Motor
No
Starting Amps
29.2
Pump
Housing Material
Cast Iron
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
GPH @ 0 feet
4320
GPH @ 5 feet
4320
GPH @ 10 feet
3660
GPH @ 15 feet
2700
GPH @ 20 feet
1500
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Submersible
Yes
Engine
Horsepower
.5 hp
Overview
Weight
38 Pounds
Product Length
10.125 Inches
Product Width
7.875 Inches
Product Height
12.06 Inches
Consumer Warranty
3 Years
UPC
053514029470
Style
Primary Sumps Pumps
GPH
4320
Gallons
Switch Type
Style
Primary
GPH
4320 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • ***NON-AUTOMATIC - Requires Float Switch***
  • Submersible Cast Iron Sump Pump
  • Offers years of reliable, trouble-free operation
  • No Sheet Metal Parts To Rust Or Corrode
  • Stainless steel screws, guard, handle, arm and seal assembly
  • Thermally Protected, Permanent Split Capacitor Motor
  • Oil-filled and hermetically sealed to prevent overheating
  • Carbon & Ceramic Shaft Seal
  • Assures maximum protection for extended pump life
  • Powder Coated Epoxy Finish
  • Provides a corrosion resistant exterior
  • Clog-Resistant Design
  • No screen to interfere with flowing debris
  • Capable of passing 1/2" diameter solids
  • Industry Leading Quality Control
  • Entire unit is pressure tested after assembly
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Running Amps
9.4
Thermal Protection
Yes
Power Cord Length
15 Feet
Oil Free Motor
No
Starting Amps
29.2
Pump
Housing Material
Cast Iron
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
GPH @ 0 feet
4320
GPH @ 5 feet
4320
GPH @ 10 feet
3660
GPH @ 15 feet
2700
GPH @ 20 feet
1500
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Submersible
Yes
Engine
Horsepower
.5 hp
Overview
Weight
38 Pounds
Product Length
10.125 Inches
Product Width
7.875 Inches
Product Height
12.06 Inches
Consumer Warranty
3 Years
UPC
053514029470
Product Specs
+
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Running Amps
9.4
Thermal Protection
Yes
Power Cord Length
15 Feet
Oil Free Motor
No
Starting Amps
29.2
Pump
Housing Material
Cast Iron
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
GPH @ 0 feet
4320
GPH @ 5 feet
4320
GPH @ 10 feet
3660
GPH @ 15 feet
2700
GPH @ 20 feet
1500
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Submersible
Yes
Engine
Horsepower
.5 hp
Overview
Weight
38 Pounds
Product Length
10.125 Inches
Product Width
7.875 Inches
Product Height
12.06 Inches
Consumer Warranty
3 Years
UPC
053514029470
Reviews
(41)
+
Zoeller N98 Reviews & Ratings
97% of Reviewers Recommend This Product
Product Q&A
(6)
+
Search Product Q&A's Answered by Jim, the Sump Pump Expert
icon-social-fb1
+
With 29.2 start up amps. Will this run on a 15 amp circuit?
David
from Wisconsin
December 22, 2014
Answer
Thank you for visiting Sump Pumps Direct. Unfortunately, this is a question that I cannot answer. As with any sump, sewage or other pump installation, all electrical connections need to be done in accordance with NEC (National Electric Code) and state and local electric codes.
+
My Zoller pump has a threaded female connector on the body. What am I expected to put between the pump body and the bottom clamp of this check valve?
BN
from California
September 17, 2014
Answer
Typical installations will include the discharge PVC Sch40 pipe screwed into the pump discharge port and extending approximately 2-3 feet above the sump basin cover. At this point, you could attach the check valve and then complete your discharge configuration. This method would allow for an easier access point for you to service your pump.
+
which float switches will work with the Zoeller N98 with its 29.2 amp start up?
Levi
from Iowa
September 08, 2013
Answer
With a running amp rating of 9.4, any of our float switches would be compatible with the Zoeller model N98 pump. The float switches we currently offer are rated to handle any sump pump rated at a 1/2HP and 15 running amps or less.
+
Is this pump capable of handling water softener and washing machine discharge? if not, which brand/model can?
Steve K
from Wisconsin
June 06, 2013
Answer
Generally, sump pumps are not recommended for use in a water softener and/or laundry application. Just about all manufacturers will void the warranty if the pump is installed and fails in this application. You might check out our selection of LAUNDRY / DRAIN PUMP SYSTEMS as most of these self contained systems are designed for laundry and water softener applications.
+
can this pump run continous 24/7. t be used in a exterior feature
Paul
from Illinois
April 30, 2012
Answer
The Zoeller pumps are not designed to operate continuously. A better option would be the StormPro model BA-50M. While the StormPro pump comes with an adjustable vertical float switch, you can use the pump without the switch. Also, please note that for continuous operation, the pump must be 3/4 submerged at all times.
+
I am torn between which Zoeller pump would be best for my application. My basement is 104' and currently takes in approximately 3" of water when there is a hard rain. The water is only on one side of the basement and never comes up on the other. Would you recommend a 1/3 hp or 1/2?
Joe
from New Jersey
January 15, 2012
Answer
Without knowing more specifics like the water table, area of the country you live in, actual square footage of your basement, etc., it really is difficult to answer. I can tell you that most average sized homes in an average water table area can usually get away with a 1/3HP or 1/2HP pump. Beware of over-sizing the pump as it could cause the pump to cycle too frequently thereby reducing the life of the pump. You don't want to just install a 3/4HP or 1HP pump just for the sake of it.
