SJE-Rhombus 30SGMPCNO - SignalMaster® Sensor Control Switch (Normally Open/High Level) w/ 30' Cord

SJE-Rhombus 30SGMPCNO - SignalMaster® Sensor Control Switch (Normally Open/High Level) w/ 30' Cord
Model: 1006045
$43.10
In-Stock
Ships Tuesday, Jan 23rd
Tax-Free (Except IL)
No Sales Tax* (Except IL)$43.10Buy Now
No Sales Tax* (Except IL)$43.10Visit Site
No Sales Tax* (Except IL)$43.10Visit Site
In-Stock
Ships Tuesday, Jan 23rd
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Shipping Info
Shipping Info
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Features
Features
  • SJE SignalMaster« Control Switch (Normally Open Contacts)
  • Used in accurately monitor HIGH liquid levels
  • For Use In Sump, Sewage & Effluent Applications
  • Rated @ 5A Max 125/250VAC - Max Water Depth 30', 13PSI
  • "High Level" Normally Open Contacts (Yellow Colored Cap)
  • Turns on (closes) when the switch tips slightly above horizontal
  • Turns off (opens) when the switch drops slightly below horizontal
  • PVC Float Housing (2.74"D x 4.83"L)
  • High impact, corrosion-resistant design for liquids up to 140 F
  • Narrow-Angle, Mechanically Activated, Snap Action Contacts
  • Provides a tight control differential of 1.5"
  • 30' SJOW CPE Cord w/ Bare Leads For Hardwiring Applications
  • Flexible, 18-gauge gauge construction that's water resistant
  • Includes Mounting Clamp
  • For apps. where switch is attached to discharge pipe or rail system
  • *Note - Not Recommended For Controlling*
  • Electrical loads less than 100 MA, 12 VAC & Non-Arch Electric Loads
  • UL Recognized For Use In Non-Potable Water & Sewage
  • 5-Year Limited Warranty
Specifications
Motor
Power Cord Length
30 Feet
Rated Capacity
5
Pump
Float Type
Tether Switch
Overview
Weight
2.34 Pounds
Product Length
360 Inches
Consumer Warranty
5 Years
Features
Features
  • SJE SignalMaster« Control Switch (Normally Open Contacts)
  • Used in accurately monitor HIGH liquid levels
  • For Use In Sump, Sewage & Effluent Applications
  • Rated @ 5A Max 125/250VAC - Max Water Depth 30', 13PSI
  • "High Level" Normally Open Contacts (Yellow Colored Cap)
  • Turns on (closes) when the switch tips slightly above horizontal
  • Turns off (opens) when the switch drops slightly below horizontal
  • PVC Float Housing (2.74"D x 4.83"L)
  • High impact, corrosion-resistant design for liquids up to 140 F
  • Narrow-Angle, Mechanically Activated, Snap Action Contacts
  • Provides a tight control differential of 1.5"
  • 30' SJOW CPE Cord w/ Bare Leads For Hardwiring Applications
  • Flexible, 18-gauge gauge construction that's water resistant
  • Includes Mounting Clamp
  • For apps. where switch is attached to discharge pipe or rail system
  • *Note - Not Recommended For Controlling*
  • Electrical loads less than 100 MA, 12 VAC & Non-Arch Electric Loads
  • UL Recognized For Use In Non-Potable Water & Sewage
  • 5-Year Limited Warranty
Specifications
Motor
Power Cord Length
30 Feet
Rated Capacity
5
Pump
Float Type
Tether Switch
Overview
Weight
2.34 Pounds
Product Length
360 Inches
Consumer Warranty
5 Years
Product Specs
+
Specifications
Motor
Power Cord Length
30 Feet
Rated Capacity
5
Pump
Float Type
Tether Switch
Overview
Weight
2.34 Pounds
Product Length
360 Inches
Consumer Warranty
5 Years
