VIAIR 2ON2 Jeep JK 12-Volt 2-Gallon 150-PSI Bolt-On High-Speed Platform System (33% Duty Cycle @ 100 PSI)

VIAIR 2ON2 Jeep JK 12-Volt 2-Gallon 150-PSI Bolt-On High-Speed Platform System (33% Duty Cycle @ 100 PSI)
Model: 30001
$599.99
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Free ShippingNo Sales Tax* (Except IL)$599.99Buy Now
Free ShippingNo Sales Tax* (Except IL)$599.99Visit Site
No Sales Tax* (Except IL)$599.99Visit Site

(as of 12:42 CST - Details) Sales Tax Extra $583.68Visit Site
Factory-Direct
Ships in 2-5 Business Days
Free Shipping
Free Shipping
*We currently CANNOT ship this product to California or any destination outside of the United States
  • Product Description
  • Reviews
  • Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Application
Consumer Grade Air Compressors
Style
DC Compressors
CFM
2.46
CFM Rated @ 90 PSI
Tank Size
2
Gallons
Application
Consumer
Style
DC Compressors
CFM
2.46 CFM Rated @ 90 PSI
Tank Size
2 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • High Pressure 12-Volt On-Board System For Up To 40" Tires
  • 2 high-output compressors are mounted to a 2-gallon, 150 PSI, 5 port air tank
  • All required components are included to complete the installation
  • Billet 1/4” NPT x 6-Port Manifold & Mounting Bracket
  • Easy-to-install wiring harness & manifold make wiring & plumbing straightforward
  • Model-specific bolt-on application for 2007-2011 Jeep JK with a crossmember mounting bracket
  • Dependable Permanent Magnetic Motor
  • 33% duty cycle at 100 PSI allows 20 minutes on, 40 minutes off run time; sealed pressure switch 110-PSI on, 145-PSI off
  • Automatic thermal overload protector prevents the compressor from overheating
  • Two 400C Air Compressors
  • Quickly & efficiently puts out 4.55 CFM flow at zero PSI head pressure; 2.46 CFM @ 90 PSI
  • Air Filter Housing with Installed Element
  • Two replacement air filter elements are included
  • Quality Connections
  • Two 1/4” stainless steel braided leader hoses with JIC connectors; 15 feet of DOT air line
  • Delphi connectors throughout; also includes two 1/4” BSP Adapters for Air Lockers
  • Illuminated Dash Panel Air Pressure Gauge
  • Marked for 0-160 PSI; easy to read at a glance
  • 60-Amp Fuse & Fuse Holder
  • 59 amp maximum amp draw; includes an 80-amp relay
Specifications
Motor
Voltage
12 Volt DC
Amp Draw
59
Pump
CFM
2.46
CFM Rated @
90 PSI
Pump Type
Single-Stage
Max PSI
150 PSI
Pump Drive
Direct Drive
Oil Type
Oil Free
Duty Cycle
100%
Tank
Tank Size
2 Gallons
Tank Included
Yes
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
30 Pounds
Product Length
18.5 Inches
Product Width
5.9 Inches
Product Height
13.5 Inches
Consumer Warranty
1 Year
UPC
818114003110
Application
Consumer Grade Air Compressors
Style
DC Compressors
CFM
2.46
CFM Rated @ 90 PSI
Tank Size
2
Gallons
Application
Consumer
Style
DC Compressors
CFM
2.46 CFM Rated @ 90 PSI
Tank Size
2 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • High Pressure 12-Volt On-Board System For Up To 40" Tires
  • 2 high-output compressors are mounted to a 2-gallon, 150 PSI, 5 port air tank
  • All required components are included to complete the installation
  • Billet 1/4” NPT x 6-Port Manifold & Mounting Bracket
  • Easy-to-install wiring harness & manifold make wiring & plumbing straightforward
  • Model-specific bolt-on application for 2007-2011 Jeep JK with a crossmember mounting bracket
  • Dependable Permanent Magnetic Motor
  • 33% duty cycle at 100 PSI allows 20 minutes on, 40 minutes off run time; sealed pressure switch 110-PSI on, 145-PSI off
  • Automatic thermal overload protector prevents the compressor from overheating
  • Two 400C Air Compressors
  • Quickly & efficiently puts out 4.55 CFM flow at zero PSI head pressure; 2.46 CFM @ 90 PSI
  • Air Filter Housing with Installed Element
  • Two replacement air filter elements are included
  • Quality Connections
  • Two 1/4” stainless steel braided leader hoses with JIC connectors; 15 feet of DOT air line
  • Delphi connectors throughout; also includes two 1/4” BSP Adapters for Air Lockers
  • Illuminated Dash Panel Air Pressure Gauge
  • Marked for 0-160 PSI; easy to read at a glance
  • 60-Amp Fuse & Fuse Holder
  • 59 amp maximum amp draw; includes an 80-amp relay
Specifications
Motor
Voltage
12 Volt DC
Amp Draw
59
Pump
CFM
2.46
CFM Rated @
90 PSI
Pump Type
Single-Stage
Max PSI
150 PSI
Pump Drive
Direct Drive
Oil Type
Oil Free
Duty Cycle
100%
Tank
Tank Size
2 Gallons
Tank Included
Yes
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
30 Pounds
Product Length
18.5 Inches
Product Width
5.9 Inches
Product Height
13.5 Inches
Consumer Warranty
1 Year
UPC
818114003110
Product Specs
+
Specifications
Motor
Voltage
12 Volt DC
Amp Draw
59
Pump
CFM
2.46
CFM Rated @
90 PSI
Pump Type
Single-Stage
Max PSI
150 PSI
Pump Drive
Direct Drive
Oil Type
Oil Free
Duty Cycle
100%
Tank
Tank Size
2 Gallons
Tank Included
Yes
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
30 Pounds
Product Length
18.5 Inches
Product Width
5.9 Inches
Product Height
13.5 Inches
Consumer Warranty
1 Year
UPC
818114003110
