SMC 3/4" Commercial Refrigerated Air Dryer 10HP (40 CFM)
Model: IDFB8E-11N
+
Share This Product
-
Product Description
-
3Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Style
Air Dryer CFM
41
Style
Refrigerated
Air Dryer CFM
41
Features
Features
- Keep Water, Oil, And Dirt Out Of Your Compressed Air
- Less corrosion of pipes and tools means less downtime
- Avoid splotches & stains on your projects with proper filtration
- Compact And Efficient
- Great for a 10 horsepower system
- 41 CFM at 37°F PDP; high performance heat exchanger
- Environmentally Safe
- Uses R134a refrigerant to prevent damage to the ozone layer; UL and CSA listed
- Easy To Install
- Uses 115v single phase power; no special wiring needed
- Simple control system with convenient evaporator gauge
- 3/4" connections; inlet air temperature of 100°F (37.8°C)
- 1 Year Factory Warranty
- Using an AFF Series Line Filter in front of your dryer extends warranty to 2 years, with 5 year coverage on the heat exchanger
Specifications
Engine
HP
10
Motor
Voltage
115 Volt AC
Phase
1-Phase
Air Dryer
Air Dryer CFM
41
Max PSI
150
Max Inlet Temp. Rating
122
Max Ambient Temp. Rating
104
Non-Cycling
Yes
Inlet Fittings
3/4"
Outlet Fittings
3/4"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
No
Auto Drain
Yes
Regenerative
No
High Temp
No
Overview
Weight
64 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
18.9 Inches
Product Width
10.6 Inches
Product Height
22.2 Inches
Power Type
Electric
Style
Air Dryer CFM
41
Style
Refrigerated
Air Dryer CFM
41
Features
Features
- Keep Water, Oil, And Dirt Out Of Your Compressed Air
- Less corrosion of pipes and tools means less downtime
- Avoid splotches & stains on your projects with proper filtration
- Compact And Efficient
- Great for a 10 horsepower system
- 41 CFM at 37°F PDP; high performance heat exchanger
- Environmentally Safe
- Uses R134a refrigerant to prevent damage to the ozone layer; UL and CSA listed
- Easy To Install
- Uses 115v single phase power; no special wiring needed
- Simple control system with convenient evaporator gauge
- 3/4" connections; inlet air temperature of 100°F (37.8°C)
- 1 Year Factory Warranty
- Using an AFF Series Line Filter in front of your dryer extends warranty to 2 years, with 5 year coverage on the heat exchanger
Specifications
Engine
HP
10
Motor
Voltage
115 Volt AC
Phase
1-Phase
Air Dryer
Air Dryer CFM
41
Max PSI
150
Max Inlet Temp. Rating
122
Max Ambient Temp. Rating
104
Non-Cycling
Yes
Inlet Fittings
3/4"
Outlet Fittings
3/4"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
No
Auto Drain
Yes
Regenerative
No
High Temp
No
Overview
Weight
64 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
18.9 Inches
Product Width
10.6 Inches
Product Height
22.2 Inches
Power Type
Electric
Product Specs
+−
Specifications
Engine
HP
10
Motor
Voltage
115 Volt AC
Phase
1-Phase
Air Dryer
Air Dryer CFM
41
Max PSI
150
Max Inlet Temp. Rating
122
Max Ambient Temp. Rating
104
Non-Cycling
Yes
Inlet Fittings
3/4"
Outlet Fittings
3/4"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
No
Auto Drain
Yes
Regenerative
No
High Temp
No
Overview
Weight
64 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
18.9 Inches
Product Width
10.6 Inches
Product Height
22.2 Inches
Power Type
Electric
