Magnetic Starter Magnetic StarterThe Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Engine
HP
1.5
Pump
CFM CFMCubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
6.9
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Max PSI Max PSIPSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler After CoolerAn aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off Pump Low Oil Shut-offPrevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
9 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve Electronic Drain ValveThe inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Portable
Weight
174 Pounds
Consumer Warranty
1 Year
Product Length
46 Inches
Product Width
19 Inches
Product Height
28 Inches
Power Type
Electric
UPC
662865268256
Reviews
(9)
Rolair 5715K17 Reviews & Ratings
Customer Photos and Videos
Product Q&A
(3)
Product QuestionsAnswered by Joshua, the Air Compressor Expert
What size is the shaft that the pulley is mounted to?
Jason W.
from Kansas
October 07, 2019
Answer
The motor shaft is 7/8" (.875").
Was this answer helpful?
Yes
0
No
0
What kind of fitting do I use for the 1/2 connector?
Shawn A.
from California
September 28, 2019
Answer
This unit has a 3/8" port. Therefore you will need 3/8" male threads on one end to thread into the port on the compressor.
Was this answer helpful?
Yes
0
No
0
how many running watts and starting watts does it take to run
Chris Handel
from Wisconsin
July 05, 2016
Answer
Unfortunately, we do not have that info. Please contact ROLAIR @ 920-349-3281 for additional assistance.
Was this answer helpful?
Yes
1
No
0
