Features
- Raintight and Bug Proof
- Easy access flanged cover
- POP-FAST™ 3/4 Inch Knockout Design
- Fast installation with 3 openings
- Slide-Out Base
- 360 degree rotation for quick terminal connections
- Large 103 cu/in interior area for heavy duty wiring
- Nema 3R Enclosure
- Indoor and outdoor rated
- High impact construction
- UL Listed
- UV stabilized ABS construction
California residents see
Warning: This product can expose you to chemicals including 1,3-Butadiene which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
Plug Types
PBN30
General Information
Product Category
Generator Accessories
Overview
Product Category
Generator Accessories
Weight
2.5 Pounds
Consumer Warranty
2 Years
Product Length
6.25 Inches
Product Width
6.25 Inches
Product Height
4.375 Inches
UPC
815181010713
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
7500 Watts
Rated Amps
30 Amps
Enclosure
NEMA 3R
Maximum Wattage
7500 Watts
UL Listed
Yes
Plugs
NEMA L14-30R
1
Reviews
(15)
Reliance Controls PBN30 Reviews & Ratings
Product Q&A
(1)
Product Questions
Answered by Jared, the Generator Expert
Will this work with a 12000 watt generator?
Marty
from North Dakota
January 19, 2021
How-To Articles
How to Winterize Your Standby Generator
A winter power outage is no picnic, especially during a sub-zero arctic blackou...
How to Pick the Perfect Gen-Cord
The most common way to use a portable electric generator is to place it outdoors...
Power Equipment How-To Library
Articles, Tips and Buying Guides from Our Experts
Manuals
Ask A Question!
*Required Fields
+
Thank You For Submitting Your Question
Your submission has been sent successfully. Please give our experts up to two business days to respond.
Media Gallery
Reliance Controls 30-Amp (4-Prong) Power Inlet Box (Non-Metallic)
