Reliance Controls Pro/Tran 2 - 30-Amp (120/240V 4-Circuit) Indoor Transfer Switch w/ Inlet
Model: 304B
+
Share This Product
-
Product Description
-
2Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Type

Amp Rating

Circuits
4
Enclosure

Type
Manual
Amp Rating
30
Circuits
4
Enclosure
NEMA 1R
Features
Features
- Pro/Tran® 2 Series 30-Amp 4-Circuit 120V Manual Transfer Swtich
- Same benefits as the original plus new some new features
- Safest Way to Distribute Power
- Eliminates dangerous backfeeds and electrical overloads
- (4) Total Circuits (1" Interchangable Style)
- Four 15-Amp Single-Pole (120 Volts) circuits
- Versatile Connection
- Allows hardwiring OR plug-in connection via power inlet (included)
- Hinged, Non-Metalic Cover
- Protects toggle swtiches/breakrs & povides a finished apperance
- Powder-Coated Steel Cabinet For Indoor Installation
- 18" Flexible conduit w/ all factory wires clearly marked/colored
- (6) Combination 1/2" & 3/4" knockouts for easier installation
- Easily re-configured in the field for multiple 2-pole circuits
- Safety & Certifications
- Certified for use by Underwriter Laboratories to UL Stanard 1008
- Meets all requirements of article 702 of the NEC ANSI/NFPA 70
- 5-Year Limited Warranty
Specifications
Plugs

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
3750 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Conduit Length
18
Number of Circuit Breakers
4
Max Generator Input
30 Amps
Maximum Wattage
3750 Watts
UL Listed
Yes
Overview
Weight
15 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
11.25 Inches
Product Width
7.75 Inches
Product Height
4.5 Inches
UPC
815181012595
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-30R
1
Type

Amp Rating

Circuits
4
Enclosure

Type
Manual
Amp Rating
30
Circuits
4
Enclosure
NEMA 1R
Features
Features
- Pro/Tran® 2 Series 30-Amp 4-Circuit 120V Manual Transfer Swtich
- Same benefits as the original plus new some new features
- Safest Way to Distribute Power
- Eliminates dangerous backfeeds and electrical overloads
- (4) Total Circuits (1" Interchangable Style)
- Four 15-Amp Single-Pole (120 Volts) circuits
- Versatile Connection
- Allows hardwiring OR plug-in connection via power inlet (included)
- Hinged, Non-Metalic Cover
- Protects toggle swtiches/breakrs & povides a finished apperance
- Powder-Coated Steel Cabinet For Indoor Installation
- 18" Flexible conduit w/ all factory wires clearly marked/colored
- (6) Combination 1/2" & 3/4" knockouts for easier installation
- Easily re-configured in the field for multiple 2-pole circuits
- Safety & Certifications
- Certified for use by Underwriter Laboratories to UL Stanard 1008
- Meets all requirements of article 702 of the NEC ANSI/NFPA 70
- 5-Year Limited Warranty
Specifications
Plugs

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
3750 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Conduit Length
18
Number of Circuit Breakers
4
Max Generator Input
30 Amps
Maximum Wattage
3750 Watts
UL Listed
Yes
Overview
Weight
15 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
11.25 Inches
Product Width
7.75 Inches
Product Height
4.5 Inches
UPC
815181012595
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-30R
1
Product Specs
+−
Specifications
Plugs

Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
3750 Watts
Rated Amps
30 Amps
Enclosure
NEMA 1R
Conduit Length
18
Number of Circuit Breakers
4
Max Generator Input
30 Amps
Maximum Wattage
3750 Watts
UL Listed
Yes
Overview
Weight
15 Pounds
Made in USA
Yes
Consumer Warranty
5 Years
Product Length
11.25 Inches
Product Width
7.75 Inches
Product Height
4.5 Inches
UPC
815181012595
Transfer Switch Circuits
15A 120V
4
Circuit Breaker Protection
Each Circuit
Plugs
NEMA L14-30R
1
