Mi-T-M 8-HP 8-Gallon Gas Two-Stage Wheelbarrow Air Compressor w/ Honda Engine
Model: AM2-PH09-08M
+
Share This Product
-
Product Description
-
4Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade

Style

Engine Brand
Honda
CFM
17.2
CFM Rated @ 175 PSI
Tank Size
8
Gallons
Grade
Contractor
Engine Brand
Honda
CFM
17.2 CFM Rated @ 175 PSI
Tank Size
8 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- This Unit Can Go Where The Big Jobs Are
- Higher CFM and air capacity can run multiple tools at once
- Handles & pneumatic tires allow easy shifting around the jobsite
- Cast Iron Cylinder & Splash Lubricated, Cast Iron Crankcase
- Rugged and durable to work hard and last a long time
- Stainless steel braided discharge hose
- 16.5 Inch Flywheel For Extra Cooling & Longer Life
- Belt tightening system pulls engine straight- keeps belt aligned
- Guard allows easy access to belts; powder coating resists rust
- Reliable Honda 8-HP OHV Engine
- Mounted on a 7 gauge base plate to reduce vibration
- Quality pilot valve unloader & large canister intake filter
- Regulator and 2 gauges for tank and outlet pressure
- Pneumatic idle control to conserve fuel
- Generous Warranty
- 2 year limited warranty on Honda engine
- 2 year limited pump exchange program
- 2 year limited warranty on the rest of the unit
Specifications
Engine
HP
8
Auto Idle
Yes
Engine Brand
Honda
Starting System
Recoil Start
Engine Low Oil Shut-off
No
Pump
CFM
17.2
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
8 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
No
Air Dryer
No
Overview
Weight
260 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
44 Inches
Product Width
26 Inches
Product Height
31 Inches
Power Type
Gas
UPC
016977990688
Grade

Style

Engine Brand
Honda
CFM
17.2
CFM Rated @ 175 PSI
Tank Size
8
Gallons
Grade
Contractor
Engine Brand
Honda
CFM
17.2 CFM Rated @ 175 PSI
Tank Size
8 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- This Unit Can Go Where The Big Jobs Are
- Higher CFM and air capacity can run multiple tools at once
- Handles & pneumatic tires allow easy shifting around the jobsite
- Cast Iron Cylinder & Splash Lubricated, Cast Iron Crankcase
- Rugged and durable to work hard and last a long time
- Stainless steel braided discharge hose
- 16.5 Inch Flywheel For Extra Cooling & Longer Life
- Belt tightening system pulls engine straight- keeps belt aligned
- Guard allows easy access to belts; powder coating resists rust
- Reliable Honda 8-HP OHV Engine
- Mounted on a 7 gauge base plate to reduce vibration
- Quality pilot valve unloader & large canister intake filter
- Regulator and 2 gauges for tank and outlet pressure
- Pneumatic idle control to conserve fuel
- Generous Warranty
- 2 year limited warranty on Honda engine
- 2 year limited pump exchange program
- 2 year limited warranty on the rest of the unit
Specifications
Engine
HP
8
Auto Idle
Yes
Engine Brand
Honda
Starting System
Recoil Start
Engine Low Oil Shut-off
No
Pump
CFM
17.2
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
8 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
No
Air Dryer
No
Overview
Weight
260 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
44 Inches
Product Width
26 Inches
Product Height
31 Inches
Power Type
Gas
UPC
016977990688
Product Specs
+−
Specifications
Engine
HP
8
Auto Idle
Yes
Engine Brand
Honda
Starting System
Recoil Start
Engine Low Oil Shut-off
No
Pump
CFM
17.2
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
8 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
No
Air Dryer
No
Overview
Weight
260 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
44 Inches
Product Width
26 Inches
Product Height
31 Inches
Power Type
Gas
UPC
016977990688
