Makita MAC5200
Makita MAC5200
Hover to zoom
1 Of 5



Product Discontinued Product Discontinued
Makita 3-HP 5.2-Gallon (Direct Drive) Cast-Iron Air Compressor
Makita 3-HP 5.2-Gallon (Direct Drive) Cast-Iron Air Compressor
Model: MAC5200
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Melissa, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Contractor

Style

Portable - Horizontal

CFM

6.5

Tank Size

5.2

  • Cast Iron Pump with Big Bore Cylinder and Piston
  • Provides faster recovery time for improved performance
  • Folding Handle
  • Low profile design for easy storage with handle folded
  • Rugged Wheels
  • Easily transport on rugged job site terrain
  • Built-in Storage Compartment
  • Conveniently stores air fittings and accessories
  • Air Hose Wrap
  • Stores 50 ft. of 3/8" air hose with handle folded or upright
  • Roll Cage
  • Extra protection to pump and motor assembly
  • Oil Sight Glass
  • Fast, easy and efficient maintenance
  • Finned Discharge Tubing
  • Increases heat dissipation and reduces moisture in the air
  • Lever Handle Ball Valve
  • Quickly remove excess moisture from the tank
  • Built-in Thermal Overload
  • Protects the motor for excess heat

Specifications

MAC5200
specs product image PID-9177
Motor
Voltage
120 Volt AC
Phase
1-Phase
Magnetic Starter Learn More
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Engine
HP
3
Pump
CFM Learn More
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
6.5
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI Learn More
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler Learn More
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Direct Drive
Oil Type
Oil Lubricated
Pump Low Oil Shut-off Learn More
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
5.2 Gallons
Tank Outlet
1/4 Inch
Tank Orientation
Horizontal
Overview
Weight
88 Pounds
Consumer Warranty
1 Year
Product Length
29 Inches
Product Width
19 Inches
Product Height
19-1/2 Inches
Power Type
Electric
UPC
088381053549
