Little Giant C20ST 80 GPH 115V Condensate Removal Pump with Safety Switch
Model:
554425
+
Share This Product
Features
Inlet Size
N/A
Style
Condensation
GPM
Gallons
- Includes safety switch
- 6 ft, 3-conductor cable with grounded 3-prong plug
- Maximum water temperature: 140 Faranheit
- Removable pump float locking tab for safety during transportation (remove at time of installation)
- Built-in wall mount tabs on tank
- Thermally protected, fan cooled motor
- Three 1-1/8" diameter inlet openings ( two fitted with removable cap plug )
- 3 / 8" O.D. barbed discharge adapter with built-in check valve
- For models with safety overflow switch: dual function NO and NC operation ( set to NO from factory for equipment shut down connection )
- Some models equipped with float ( solid polymer ) activated switch for automatic high level water detection ( safety overflow switch )
- Automatic start and stop operation
- Vertical centrifugal pump design
- 1 / 2 gallon collection tank
- Our SKU number(s): Little Giant 554425
- The manufacturer model number(s): Little Giant 554425
Specifications
554425
General Information
Type
Condensate Pump
Product Category
Mini Split Accessories
Electrical Data
Power Consumption
93 Watts
Phase
1
Frequency
60 Hz
Performance
Maximum Shut Off
20 feet
Dimensions
Product Height
7 Inches
Product Width
9 19/24 Inches
Product Length
5 Inches
Product Weight
5 Pounds
Power Cord Length
6 Feet
Pump
Max Head
20 Feet
Submersible
No
Overview
Product Category
Water Pump
Weight
5 Pounds
UPC
010121544253
