Kohler Command Pro CH980 999cc 35 Gross HP Electric Start Horizontal Engine, 1-7/16" x 4.45" Crankshaft, Tapped 5/8"-18

Model:

PA-CH980-3000

Write a Review
$2,699.99
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Kohler Command Pro CH980 999cc 35 Gross HP Electric Start Horizontal Engine, 1-7/16
Kohler Command Pro CH980 999cc 35 Gross HP Electric Start Horizontal Engine, 1-7/16" x 4.45" Crankshaft, Tapped 5/8"-18
Model: PA-CH980-3000
$2,699.99
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

  • Model# CH980-3000, 1-7/16" x 4.45" Crankshaft, Tapped 5/8"-18
  • Utility / General applications like mowers, compressors & grain augers
  • KOHLER Command PRO CH980 V-Twin Cylinder Air-Cooled 4-Cycle Horizontal Gas Engine
  • Produces 54.5 lbs./ft. peak torque- Power levels are stated gross torque per SAE J2003
  • Top Mounted, Quick Change Oil Filter
  • Easy to reach- access to entire cylinder for thorough cleaning
  • Less mess- most of oil is drained before removal
  • Only one tool needed to remove cylinder cover
  • Overhead Valve Technology
  • Produces more power, improved fuel economy/cooling, and reduces oil consumption
  • Provides greater volumetric efficiency and higher compression ratio
  • Virtually no carbon buildup, reducing overall maintenance costs
  • Fully Oil Pressurized Hydraulic Valve Lifters
  • Push rods stay in constant contact with rocker arms
  • Valve train is maintenance free- no adjustments needed
  • KOHLER Command PRO
  • Generates a stronger spark at low cranking speed
  • High-Efficiency Fan and Screen
  • Modulated cooling fan keeps engine cooler
  • Integrated Oil Cooler
  • Spin on, full-flow oil filter keeps debris and particles out of engine
  • Variable Speed, Mechanical Governor
  • Smooth performance, regardless of application or fluctuating demands for power
  • 12V Electric Starter & 25A Regulated Charging System
  • Mechanical Fuel Pump- Gas Tank Not Included
California residents see
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

PA-CH980-3000
Engine
Engine Series
Command Pro
Engine Style
Horizontal
Engine Type
4-Cycle OHV
Cylinders
2
Cooling System
Air
Dry Weight
132 Lbs
CC
999 CCs
HP
35 HP
Max Torque
54.5 Lbs
Cylinder Bore Type
Cast Iron
Bore
3.5 Inches
Stroke
3.1 Inches
Compression Ratio
8.8:1
CARB
Yes
Systems
Charging System
25 Amps
Starting System
12-Volt Key Start
Ignition System
Electronic Spark
Lubrication
Lubrication
Pressurized
Oil Capacity
67.2 oz
Intake/Exhaust
Fuel
Gas
Muffler
Not Included
Air Cleaner
Mult-Stage Canister
Fuel Tank
Not Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
1-7/16 x 4.45 Inch
Crankshaft Type
Straight
Crankshaft Diameter
1-7/16"
Crankshaft Length
4.45"
Crankshaft End Tapped Size
5/8"-18
Crankshaft Keyway Width
3/8 Inches
PTO Height
6-1/8 Inches
Overview
Weight
132 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Length
15.3 Inches
Product Width
19 Inches
Product Height
27.5 Inches
Dimensions
15.3 x 19.0 x 27.5
