Kohler 14KW Aluminum Standby Generator System (100A Indoor 16-Circuit Switch)

Model:

14RCAL-100LC16

Write A Review
$4,840.00
rebate icon
$100 Mail-In Rebate - Click Here For Printable Form
$100 Referral Rebate
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 4-6 Weeks
synchrony card logo
$85 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Kohler 14KW Aluminum Standby Generator System (100A Indoor 16-Circuit Switch)
Kohler 14KW Aluminum Standby Generator System (100A Indoor 16-Circuit Switch)
Model: 14RCAL-100LC16
$4,840.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jared, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Emergency

Style

Standby (Air Cooled)

Run Watts

14,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

LP/Natural Gas

Engine

Kohler

  • 14kW (LPG) / 12kW (NG) Air-Cooled Standby Generator
  • Protects your home and family during a power outage
  • Includes Kohler 100-Amp Automatic Transfer Switch
  • Designed for indoor installations w/ 16-Circuit Load Center
  • Kohler Command PRO® OHV Engine
  • Meets emission regulations for U.S. EPA & California
  • Powerful and reliable engine with hydraulic valve lifters
  • New 100% Corrosion-Proof Aluminum Enclosure
  • Aluminum base can be mounted on gravel or cement pad
  • Meets 181 MPH wind rating; Impact-resistant down to -30° F
  • Powerful Performance w/ PowerBoost™ Technology
  • Greater motor-starting ability for large electrical loads
  • Premium Power Quality (+/-1% Voltage Regulation)
  • Protects sophisticated electronics with low distortion (<5%THD)
  • Fast Response Time
  • Kohler™ generators restore power in as little as 10 seconds
  • New Silencer Reduces Sound Levels & Provides Quiet Operation
  • Maintains neighborhood solitude - approx 67 dB(A) at 7 m (23 ft)
  • RDC2 (6-Button) Digital Controller
  • Glare-resistant, 2-line 16-character display - No More Codes
  • ATS status via LED lights on controller; Built-In 2.5A Battery Charger
  • Real time clock allows you to easily set weekly exercise
  • OnCue® Plus Remote Monitoring System (Included)
  • Built-in Ethernet card, no hardware needed for OnCue
  • Requires OnCue Plus Wireless Radio Kit For Wireless Monitoring (Sold Separately)
  • KOHLER® Energy Management App
  • Get real-time alerts on generator status, remote control & maintenance records
  • Easier Installation
  • Streamline design reduces time required to install generator
  • Installation Flexibility*
  • Can be installed within 18" of a building / home
  • *Always check local building codes
  • Premium Warranty - 5-Year / 2,000-Hour Limited Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

14RCAL-100LC16
specs product image PID-102503
General Information
Product Category
Generator - Standby
Overview
Product Category
Generator - Standby
Weight
440 Pounds
CARB Compliant
Yes
Made in USA
Yes
Consumer Warranty
5 Years
Commercial Warranty
5 Years
Product Style
Standby Generator
Product Length
47 Inches
Product Width
26.2 Inches
Product Height
32.2 Inches
UPC
650531446756
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Rated Watts
14000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
12000 Watts
LP Power Capacity
14000 Watts
NG Fuel Consumption @ 50% Load
124 ft³/hr
NG Fuel Consumption @ 100% Load
193 ft³/hr
LP Fuel Consumption @ 50% Load
1.8 gallons/hr
LP Fuel Consumption @ 100% Load
2.3 gallons/hr
Rated Amps
58 Amps
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
62 Test (67 Run) dbA
Transfer Switch
Automatic (Included)
Transfer Switch Amperage
100-Amps
Max Circuits
16
Battery
Not Included (500 CCA)
Enclosure
Aluminum
A/C Ton Rating
5-Tons
Transfer Switch Style
Standard Installation
ATS Load Prioritizing
Not Compatible
ATS Load Shedding
Not Compatible
ATS Service Disconnect
No
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Wi-Fi Remote Monitoring
Sold Separately
Engine
Engine Brand
Kohler
Starting System
12v Auto Start
CC
725 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
