Ingersoll Rand Next Generation R-Series 50-HP Rotary Compressor w/ Total Air System Dryer (230V 3-Phase 118PSI)

Model:

RS37I-A118-TAS.230V3

Write a Review
$25,566.00
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 3-4 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
Free Shipping$25,566.00Buy Now
Free Freight$25,566.00Visit Site
Ingersoll Rand Next Generation R-Series 50-HP Rotary Compressor w/ Total Air System Dryer (230V 3-Phase 118PSI)
Ingersoll Rand Next Generation R-Series 50-HP Rotary Compressor w/ Total Air System Dryer (230V 3-Phase 118PSI)
Model: RS37I-A118-TAS.230V3
$25,566.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Joshua, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Commercial

Style

Rotary Screw 3-Phase

CFM

220

Tank Size

0



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • This Unit Is Too Large For Liftgate Service, Must Have A Shipping Dock Or Forklift
  • Next Generation R-Series 50-HP Rotary Screw Air Compressor
  • Boosts productivity, lowers operating expenses and extends equipment life
  • Total Air System (TAS) Package
  • Includes space-saving, ready-to-run, pre-mounted dryer and filters for cleaner, dryer air
  • State Of The Art Airend
  • Delivers as much as 18% improved efficiency and best-in-class airflow capacity
  • Provides up to 220 CFM at 118 PSI with 100% duty cycle
  • Programmable Xe-Series Color Controller With Remote Connectivity
  • Intuitive, high-resolution color display offers remote access with any common, current web browser
  • Built-in optimization sequencer for up to four units; programmable start/stop operation & remote connectivity
  • PAC™ Protection
  • Scans & adjusts operation in response to filtration changes; real-time maintenance indicators & shutdown protection
  • Free-Floating Cooling System Rated For 115°F (46°C) Ambient
  • Optimized, energy-efficient & low-noise centrifugal blower with electronic no-loss condensate drain
  • V-Shield™ Technology
  • Stainless steel air piping & metal-flex hoses have leak-free connections with superior elastometric seals
  • High-efficiency TEFC IP55 Motor
  • Class F insulation with B rise, Star-delta reduced voltage starter, & NEMA 4/IP55 electronics provide reliable service
  • Noise attenuation enclosure & vibration isolation pads reduce workplace noise
  • Simple single air inlet & single air outlet design incorporates easily into varied applications
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

RS37I-A118-TAS.230V3
specs product image PID-75379
Motor
Voltage
230 Volt AC
Phase
3-Phase
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
50
Pump
CFM
220
CFM Rated @
118 PSI
Max PSI
118 PSI
Pump Type
Rotary
After Cooler
Yes
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Duty Cycle
100%
Tank
Tank Size
0 Gallons
Tank Included
No
Electronic Drain Valve
Yes
Accessories
Air Dryer
Yes
Air Filter
Yes
Overview
Weight
2646 Pounds
Commercial Warranty
1 Year
Product Length
76 Inches
Product Width
42 Inches
Product Height
60 Inches
Power Type
Electric
