Features
Style
Refrigerated
Dryer Voltage
115V 1-Phase
Air Dryer CFM
25
Rated HP
7.5
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
- For Use With Compressors With Aftercoolers
- Keeps damp air from rusting tools & washing away lubricants
- ISO Class 6 Dryer Is Reliable And Operationally Efficient
- 25 CFM with exceptionally low pressure drop
- Integral stainless steel moisture separation
- Continuous Pressure Class H Dew Point Performance
- Optimized pressure 50°F dew point
- Temperature driven variable speed fan for continuous heat removal
- Electronic solenoid drain valve for optimal performance
- User Friendly Controls
- Simple, easy to read control panel uses a color coded diagram
- Environmentally Friendly
- Uses 115V, 1 phase power and R134A refrigerant
- Sturdy, powder coated finish
- Aluminum braze plate heat exchanger
- Professional Features
- Maximum pressure of 203PSI
- Maximum inlet temperature of 140°F; maximum ambient temp 122°F
- 1/2" NPT inlet & outlet fittings
- Installation of an upstream 1.0 micron prefilter is recommended
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
23231822
General Information
Product Category
Air Compressor Accessories
Air Dryer
Dryer Voltage
115V 1-Phase
Air Dryer CFM
Air Dryer CFM
All compressed air dryers have a maximum drying capacity expressed in Cubic Feet Per Minute (CFM)
25
Max PSI
Max PSI
The most amount of PSI that be passed through a dryer
203
Max Inlet Temp. Rating
Max Inlet Temp. Rating
The highest temperature the compressed air can be passing through the dryer for the dryer to operate properly and effectively
140
Max Ambient Temp. Rating
Max Ambient Temp. Rating
Ambient temperature is the air temperature of any object or environment where equipment is stored
122
Non-Cycling
Non-Cycling
Non-cycling refrigerated air dryers have refrigeration compressors that start as soon as you turn the dryer on ― and don't stop until you turn the dryer off. They are less expensive than cycling dryers and are a good choice for applications where they will constantly run at full capacity
Yes
Inlet Fittings
1/2"
Outlet Fittings
1/2"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Auto Drain
Auto Drain
Auto drain or drip leg drain used to drain air line of condensate and water
Yes
Alarm Lights
Yes
Regenerative
No
High Temp
High Temp
Dryers that are specifically designed to handle higher inlet temperatures than regular dryers. Typically paired with a piston or reciprocating air compressor
No
Rated HP
Rated HP
Possible corresponding compressor HP
7.5
Overview
Product Category
Air Compressor Accessories
Weight
60 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
18 Inches
Product Width
16 Inches
Product Height
18 Inches
Power Type
Electric
UPC
678384318228
Additional Model Numbers
D42IN, 23231822
Reviews
(5)
Ingersoll Rand 23231822 Reviews & Ratings
Product Q&A
(1)
Product Questions
Answered by Melissa, the Air Compressor Expert
Does this dryer have any kind of internal filter, or is it still recommended to use an external line filter after the dryer?
