Industrial Air 10-HP 120-Gallon Two-Stage Air Compressor (208-230V 1-Phase )
Industrial Air 10-HP 120-Gallon Two-Stage Air Compressor (208-230V 1-Phase )
+
Share This Product
-
Product Description
-
1Reviews
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
CFM
35
CFM Rated @ 100 PSI
Tank Size
120
Gallons
Grade
Consumer
CFM
35 CFM Rated @ 100 PSI
Tank Size
120 Gallons
Features
Features
- Baldor Industrial Class Electric Motor
- High quality 4 pole, 1725 RPM, UL certified, NEMA rated
- Wires easily into your 208-230 volt, 1-phase system
- Patented Cast Iron 2-Stage Pump Design
- Delivers 35 CFM at 100 PSI; 33.6 CFM at 175 PSI
- Provides for a cooler running pump & improves compression efficiency
- Patented Asymmetrical Cooling Fins
- Draws heat away from the precision bored cylinders
- Patented Cast Iron Flywheel
- Large, extended fins improve pump cooling & lower RPMs
- Pre-Wired Magnetic Starter
- Protects your compressor from being overloaded
- 120 Gallon Vertical ASME Tank With Vibration Isolation Pads
- Extended tank drain valve and ball valve for ease of use
- Operates a wider range of tools & provides longer run time
- Large Oil Sight Glass
- Quickly check pumps oil level with ease
- Extra capacity oil reservoir ensures lower oil
- 2 Year Limited Factory Warranty
- Purchase & use of maintenance kit doubles the pump warranty
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
42
Recommended Breaker
60 Amp Breaker
Engine
HP
10
Pump
CFM
35
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
120 Gallons
Tank Included
Yes
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Air Dryer
No
Overview
Weight
1025 Pounds
Certification
ASME, UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
51 Inches
Product Width
49 Inches
Product Height
84 Inches
Power Type
Electric
UPC
846212057056
Grade
Style
CFM
35
CFM Rated @ 100 PSI
Tank Size
120
Gallons
Grade
Consumer
CFM
35 CFM Rated @ 100 PSI
Tank Size
120 Gallons
Features
Features
- Baldor Industrial Class Electric Motor
- High quality 4 pole, 1725 RPM, UL certified, NEMA rated
- Wires easily into your 208-230 volt, 1-phase system
- Patented Cast Iron 2-Stage Pump Design
- Delivers 35 CFM at 100 PSI; 33.6 CFM at 175 PSI
- Provides for a cooler running pump & improves compression efficiency
- Patented Asymmetrical Cooling Fins
- Draws heat away from the precision bored cylinders
- Patented Cast Iron Flywheel
- Large, extended fins improve pump cooling & lower RPMs
- Pre-Wired Magnetic Starter
- Protects your compressor from being overloaded
- 120 Gallon Vertical ASME Tank With Vibration Isolation Pads
- Extended tank drain valve and ball valve for ease of use
- Operates a wider range of tools & provides longer run time
- Large Oil Sight Glass
- Quickly check pumps oil level with ease
- Extra capacity oil reservoir ensures lower oil
- 2 Year Limited Factory Warranty
- Purchase & use of maintenance kit doubles the pump warranty
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
42
Recommended Breaker
60 Amp Breaker
Engine
HP
10
Pump
CFM
35
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
120 Gallons
Tank Included
Yes
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Air Dryer
No
Overview
Weight
1025 Pounds
Certification
ASME, UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
51 Inches
Product Width
49 Inches
Product Height
84 Inches
Power Type
Electric
UPC
846212057056
Product Specs
+−
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
42
Recommended Breaker
60 Amp Breaker
Engine
HP
10
Pump
CFM
35
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
120 Gallons
Tank Included
Yes
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Air Dryer
No
Overview
Weight
1025 Pounds
Certification
ASME, UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
51 Inches
Product Width
49 Inches
Product Height
84 Inches
Power Type
Electric
UPC
846212057056
