Industrial Air 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)

Industrial Air 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)
Our Price
Compare Prices
Shipping Info
Model: IV5076055
(Based on expert analysis, manufacturer ratings and customer reviews)
4.7 out of 54.7 out of 54.7 out of 54.7 out of 54.7 out of 5
Number of Reviews (10)
Write A Review
$1,252.99
$1,127.69
In-Stock
Ships from Industrial Air
Factory items ship direct from the manufacturer
Shipping times vary
Free Shipping
Holiday Shipping Schedule
Holiday Schedule -
Add-Ons
+$75.00
Free Shipping$1,252.99$1,127.69Buy Now
Free Freight$1,127.69Visit Site
In-Stock
Ships from Industrial Air
Ships in 2-5 Business Days
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • 10
    Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Commercial
Style
Two Stage 1-Phase
CFM
15.3
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
15.3 CFM Rated @ 100 PSI
Tank Size
60 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Patented 2-Stage Pump Design
  • Runs cooler, lasts longer
  • Patented Piston Design
  • Improved compression efficiency for optimum performance
  • High efficiency finned copper intercooler increases valve life
  • Patented Asymmetrical Cooling Fins
  • Draws heat away from the precision bored cylinders
  • Patented Cast Iron Flywheel
  • Large, extended fins improve pump cooling & lower RPMs
  • Electric Motor With Thermal Overload Protection
  • Protects the motor from voltage fluctuations
  • Wires easily into your 240 volt, single phase system
  • Magnetic starter not required
  • Compact 60-Gallon ASME Air Tank
  • 15.3 CFM at 100 PSI; 13.5 CFM at 175 PSI; 3/4" air outlet
  • Optimizes shop space compared to a horizontal tank
  • Unique Metal Belt Guard Design
  • Improves pump cooling by as much as 60% over other designs
  • 2 Year Factory Warranty
  • Protects your investment
Specifications
Engine
HP
5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Vertical
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
424 Pounds
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
UPC
846212057704
Grade
Commercial
Style
Two Stage 1-Phase
CFM
15.3
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
15.3 CFM Rated @ 100 PSI
Tank Size
60 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Patented 2-Stage Pump Design
  • Runs cooler, lasts longer
  • Patented Piston Design
  • Improved compression efficiency for optimum performance
  • High efficiency finned copper intercooler increases valve life
  • Patented Asymmetrical Cooling Fins
  • Draws heat away from the precision bored cylinders
  • Patented Cast Iron Flywheel
  • Large, extended fins improve pump cooling & lower RPMs
  • Electric Motor With Thermal Overload Protection
  • Protects the motor from voltage fluctuations
  • Wires easily into your 240 volt, single phase system
  • Magnetic starter not required
  • Compact 60-Gallon ASME Air Tank
  • 15.3 CFM at 100 PSI; 13.5 CFM at 175 PSI; 3/4" air outlet
  • Optimizes shop space compared to a horizontal tank
  • Unique Metal Belt Guard Design
  • Improves pump cooling by as much as 60% over other designs
  • 2 Year Factory Warranty
  • Protects your investment
Specifications
Engine
HP
5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Vertical
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
424 Pounds
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
UPC
846212057704
Product Specs
+
Specifications
Engine
HP
5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Vertical
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
424 Pounds
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
UPC
846212057704
Reviews
(10)
+
Industrial Air IV5076055 Reviews & Ratings
89% of Reviewers Recommend This Product
Product Q&A
(1)
+
Search Product Q&A's Answered by Gabrielle, the Air Compressor Expert
icon-social-fb1
+
What is the motor RPM?
Kevin
from Texas
December 06, 2018
Answer
The motor runs at 3450 RPM.
