Husqvarna TR317C (17") 208cc Counter Rotating Rear Tine Tiller

Husqvarna TR317C (17") 208cc Counter Rotating Rear Tine Tiller
Model: 960 93 00-29
$699.99
Only 2 In-Stock
Ships Monday, Aug 20th
Free Shipping
Add-Ons
+$50.00
Extended Warranty
Excludes CA

In-Stock Free ShippingNo Sales Tax* (Except IL)$699.99Buy Now
In-Stock Free FreightNo Sales Tax* (Except IL)$699.99Visit Site
No Sales Tax* (Except IL)$749.99Visit Site
Only 2 In-Stock
Ships Monday, Aug 20th
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, California, Hawaii or any destination outside of the United States
Share
  • Product Description
  • 8
    Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Stirring
Stirring
Yes
Breaking
Breaking
Hard SoilHard Soil
Engine
Tines
Rear Tine Tillers
Tine Rotation
Forward/Counter Rotation
Width / Depth
17 / 6
Stirring
Yes
Breaking
Hard Soil
Engine
Husqvarna
Tines
Rear
Tine Rotation
Counter
Width / Depth
17 / 6 Inches
Features
Features
  • Husqvarna HX208 Engine
  • Counteracts forward momentum reducing operator fatigue
  • 9 lb-ft gross torque
  • 210 rpm rotational speed
  • Provides torque needed to cultivate the most compact soil
  • 17-Inch Tilling Width With Rear Tine Design
  • 6" working depth
  • 7 depth adjustments
  • Wide design allows you to work faster
  • Counter Rotating Tines
  • Functions as a counter rotating deep soil tiller
  • Lifetime limited warranty on tiller tines
  • Sealed Chain Gear Transmission
  • One gear forward and one reverse
  • Improves maneuverability and control
  • Counterweights
  • Counterweight increases weight on the wheels and improves balance
  • Provides safer operation
  • Easy Adjust Drag Bar
  • For balance in different working conditions
Specifications
Engine
Engine Brand
Husqvarna
Starting System
Recoil Start
Engine Cycle
4-Cycle
CC
208 CCs
Fuel Tank Size
.75 Gallons
Engine Cylinders
1 Cylinder
Torque
9.5 Lbs
Consumer Engine Warranty
5 Years
Tines
Tine Position
Rear
Tine Direction
Counter Rotation
Tine Diameter
10 Inches
Depth Adjustments
7 Positions
Tine RPM
210
Tilling Width Min
17 Inches
Tilling Width Max
17 Inches
Tilling Depth Min
3 Inches
Tilling Depth Max
6 Inches
Drive
Transmission
Chain Gear
Forward Speeds
1 Forward
Reverse Speeds
1 Reverse
Accessories
Side Shield
Yes
Hour Meter
Sold Separately
Wheels
Front Tire Size
16 Inch
Tire Type
Pneumatic Wheels
Overview
Made in USA
Yes
Weight
200 Pounds
Product Length
48 Inches
Product Width
23.5 Inches
Product Height
33 Inches
Consumer Warranty
3 Years
UPC
085388592989
Stirring
Stirring
Yes
Breaking
Breaking
Hard SoilHard Soil
Engine
Tines
Rear Tine Tillers
Tine Rotation
Forward/Counter Rotation
Width / Depth
17 / 6
Stirring
Yes
Breaking
Hard Soil
Engine
Husqvarna
Tines
Rear
Tine Rotation
Counter
Width / Depth
17 / 6 Inches
Features
Features
  • Husqvarna HX208 Engine
  • Counteracts forward momentum reducing operator fatigue
  • 9 lb-ft gross torque
  • 210 rpm rotational speed
  • Provides torque needed to cultivate the most compact soil
  • 17-Inch Tilling Width With Rear Tine Design
  • 6" working depth
  • 7 depth adjustments
  • Wide design allows you to work faster
  • Counter Rotating Tines
  • Functions as a counter rotating deep soil tiller
  • Lifetime limited warranty on tiller tines
  • Sealed Chain Gear Transmission
  • One gear forward and one reverse
  • Improves maneuverability and control
  • Counterweights
  • Counterweight increases weight on the wheels and improves balance
  • Provides safer operation
  • Easy Adjust Drag Bar
  • For balance in different working conditions
Specifications
Engine
Engine Brand
Husqvarna
Starting System
Recoil Start
Engine Cycle
4-Cycle
CC
208 CCs
Fuel Tank Size
.75 Gallons
Engine Cylinders
1 Cylinder
Torque
9.5 Lbs
Consumer Engine Warranty
5 Years
Tines
Tine Position
Rear
Tine Direction
Counter Rotation
Tine Diameter
10 Inches
Depth Adjustments
7 Positions
Tine RPM
210
Tilling Width Min
17 Inches
Tilling Width Max
17 Inches
Tilling Depth Min
3 Inches
Tilling Depth Max
6 Inches
Drive
Transmission
Chain Gear
Forward Speeds
1 Forward
Reverse Speeds
1 Reverse
Accessories
Side Shield
Yes
Hour Meter
Sold Separately
Wheels
Front Tire Size
16 Inch
Tire Type
Pneumatic Wheels
Overview
Made in USA
Yes
Weight
200 Pounds
Product Length
48 Inches
Product Width
23.5 Inches
Product Height
33 Inches
Consumer Warranty
3 Years
UPC
085388592989
Product Specs
+
Specifications
Engine
Engine Brand
Husqvarna
Starting System
Recoil Start
Engine Cycle
4-Cycle
CC
208 CCs
Fuel Tank Size
.75 Gallons
Engine Cylinders
1 Cylinder
Torque
9.5 Lbs
Consumer Engine Warranty
5 Years
Tines
Tine Position
Rear
Tine Direction
Counter Rotation
Tine Diameter
10 Inches
Depth Adjustments
7 Positions
Tine RPM
210
Tilling Width Min
17 Inches
Tilling Width Max
17 Inches
Tilling Depth Min
3 Inches
Tilling Depth Max
6 Inches
Drive
Transmission
Chain Gear
Forward Speeds
1 Forward
Reverse Speeds
1 Reverse
Accessories
Side Shield
Yes
Hour Meter
Sold Separately
Wheels
Front Tire Size
16 Inch
Tire Type
Pneumatic Wheels
Overview
Made in USA
Yes
Weight
200 Pounds
Product Length
48 Inches
Product Width
23.5 Inches
Product Height
33 Inches
Consumer Warranty
3 Years
UPC
085388592989
Reviews
(8)
+
Husqvarna 960 93 00-29 Reviews & Ratings
Product Q&A
(1)
+
Search Product Q&A's Answered by Jake, the Tiller Expert
icon-social-fb1
+
I am interesting in ordering a rear tine tiller and would like to know what is the difference in counter rotation and dual rotation
Daryll Amberg
from Wisconsin
May 26, 2013
Answer
Daryll,

Dual rotation allows you to till with your tines moving forward away from you and backwards towards you. The reverse rotation is called counter rotation, and that is best for a deeper till. Forward rotation is mainly for cultivating.

Tillers that are labeled counter rotating only have the reverse function.
