Husqvarna TR314C (14") 208cc Counter Rotating Rear Tine Tiller

Model:

TR314C

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Husqvarna TR314C (14
Husqvarna TR314C (14") 208cc Counter Rotating Rear Tine Tiller
Model: TR314C
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

  • Husqvarna HX208 Engine
  • Provides torque needed to cultivate the most compact soil
  • 9 lb-ft gross torque
  • 210 rpm rotational speed
  • 14-Inch Tilling Width With Rear Tine Design
  • 6" working depth
  • 7 depth adjustments
  • Counter-Rotating Tines
  • Functions as a counter rotating deep soil tiller
  • Lifetime limited warranty on tiller tines
  • Sealed Chain Gear Transmission
  • One gear forward and one reverse
  • Improves maneuverability and control
  • Agricultural Tires
  • Heavy treads provide better grip in cultivated and muddy soil
  • Counterweights
  • Counterweight increases weight on the wheels and improves balance
  • Provides safer operation
  • Easy Adjust Drag Bar
  • For balance in different working conditions
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm..
For more information go to: www.p65Warnings.ca.gov

Specifications

TR314C
specs product image PID-81459
Engine
Engine Brand
Husqvarna
Starting System
Recoil Start
Engine Cycle
4-Cycle
CC
208 CCs
Fuel Tank Size
.75 Gallons
Engine Cylinders
1 Cylinder
Torque
9 Lbs
Consumer Engine Warranty
5 Years
Tines
Tine Position
Rear
Tine Direction
Counter Rotation
Tine Diameter
10 Inches
Depth Adjustments
7 Positions
Tine RPM
210
Tilling Width Min
14 Inches
Tilling Width Max
14 Inches
Tilling Depth Min
3 Inches
Tilling Depth Max
6 Inches
Overview
Weight
190 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Product Length
48 Inches
Product Width
23.5 Inches
Product Height
33 Inches
UPC
085388592972
Additional Model Numbers

960 93 00-28, TR314C

Drive
Forward Speeds
1 Forward
Reverse Speeds
1 Reverse
Transmission
Chain Gear
Accessories
Side Shield
Yes
Hour Meter
Sold Separately
Wheels
Front Tire Size
13 x 5 Inch
Tire Type
Pneumatic Wheels
