Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller

Model:

MLT4060MVD-STD3

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller
Generac Mobile 6kW Narrow Body Towable Diesel Vertical Mast LED Light Tower w/ AVR, Manual Winch & Power Zone Controller
Model: MLT4060MVD-STD3
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

Grade

Style

Tow-Behind

Run Watts

6,000 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Diesel

Engine

Mitsubishi

  • Generac MLT4060MVD-STD3 6kW Towable Diesel LED Light Tower (Electric Winch)
  • Powerful, compact illumination for a variety of applications
  • (4) x 320W (47K/188K Lumens) LED Light Fixtures
  • IP68 LED Modules with 50,000-hour life
  • Aluminum / Poly construction housing and cabinet mounted LED drivers
  • 23-Foot, 5-Section Vertical Mast w/ Electric Winch
  • 359° Ground rotational mast with mast fully extended
  • Allows for quick setup, Raises mast in 15 seconds
  • Distinctive angle fixture mount for common light distribution
  • .95L Mitsubishi® L3E ECOSpeed Liquid Cooled Diesel Engine (EPA Tier 4 Final)
  • User-friendly, low maintenance, 1000-Hour service interval
  • Provides greater fuel efficiency by reducing engine speed based on demand
  • 104-Gallon Polyethylene Internal Fuel Tank
  • Allows for run times up to 530 hours with LED lighting load
  • 120/240V - 50/25A Marathon Electric® Brushless Alternator
  • Robust design provides up to 6 kW of standby output
  • Long life & low maintenance while providing +/- 1% voltage reg. (AVR)
  • Power Zone® Autolight Controller
  • Automated dusk to dawn or 7-day scheduler operation
  • Improved Engine Control System
  • Back-lit LCD display with programmable service timers and one-touch starting
  • Digital hour meter; Automatic low oil pressure/high temp. shutdown
  • (1) 120V 20A GFCI Duplex Outlet & (1) 120/240V 30A (L14-30R) Twistlock Outlet
  • Individually breakered for added safety during operation
  • Corrosion-Proof Aluminum Enclosure
  • Central lifting point and fork pockets
  • Sound rating: 63 db(A) @ 23'
  • Tubular Steel Trailer w/ (4) 2000 lb. Tube & Sleeve Leveling Jacks
  • DOT-approved LED tail, side, brake & directional lights; 15" 6-ply tires
  • 2" Ball hitch and safety chains with spring loaded safety hooks
  • Includes Starting Battery
  • CUSTOMERS MUST UNLOAD FROM FREIGHT CARRIER
  • 2-Year / 2,000 Hour Limited Warranty
  • 10,000 Hour Parts Warranty On LED Modules & Drivers
California residents see
Warning: This product can expose you to chemicals including Diesel engine exhaust which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

Plug Types
NEMA 5-20R (GFCI)
NEMA 5-20R (GFCI)
MLT4060MVD-STD3
specs product image PID-113748
Overview
Weight
1694 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
124.8 Inches
Product Width
68.4 Inches
Product Height
100.8 Inches
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
6000 Watts
Fuel Type
Diesel
Tank Size
104 Gallons
Fuel Tank Material
Plastic Resin
Decibel Rating @ 7m Learn More
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
63
Idle Control
Yes
Hour Meter
Yes
Lifting Eye
Yes
Battery
Included
Enclosure
Aluminum
Fuel Consumption
0.195 gallons/hr
Engine
Engine Brand
Mitsubishi
Starting System
12-Volt Key Start
CC
950 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
1800 RPM
Low Oil Alert/Shutdown
Yes
Plugs
NEMA 5-20R - GFCI
2
