Features
- Back protection wire net not included - Sold Separately.
- Reactive Temperature Monitoring
- Daikin ductless systems do not require any setting changes to keep your home comfortable on a hot or cool day. Once you set a temperature for the system to maintain, the system automatically adjusts output levels according to environmental conditions.
- Side protection wire net not included - Sold Separately.
- Inverter Technology Prevents Temperature Fluctuation
- Anti-Corrosion Treatment on Heat Exchanger
- The 3MXS24RMVJU unit comes with inverter technology. This works together with the expansion valve to adjust coolant flow and compressor speed to match indoor conditions. This results in less dramatic temperature swings and a more comfortable home.
- Auto restart after a power failure
- Design Your System from the Ground Up
- Self Diagnostics with Digital Display
- The Daikin 3MXS24RMVJU outdoor condenser is compatible with wall mounted, concealed duct, floor mounted, and ceiling cassette indoor units, allowing you to mix and match unit types to design a system that perfectly matches your home's needs.
- Auto fan speed control
- Low Ambient Cooling
- Auto Changeover
- MXS condensers will continue to operate optimally even in colder climates. With an operational cooling range down to 14°F, and a heating range down to 5°F, the MXS can provide heating or cooling in any enviroment.
- Quiet Operation
- Outdoor Sound Pressures as Low as 50 dB(A)
- Product Compatability
- Inverter Compressor
- Daikin CTXS Wall Mounted Indoor Units
- Our SKU number(s): Daikin 3MXS24NMVJU
- Daikin FTXS Wall Mounted Indoor Units
- The manufacturer model number(s): Daikin 3MXS24NMVJU
- Daikin FDXS Concealed Duct Indoor Units
- Daikin FFQ Ceiling Cassette Indoor Units
- Daikin FVXS Floor Mounted Indoor Units
- Line Set - This double insulated tubing transfers refrigerant efficiently between your outdoor condenser and indoor units.
- Drain Tubing - Drain tubing facilitates the reliable and effective removal of condensate from your system. It connects your indoor units to drain locations of your choosing..
- Disconnect Box & Electrical Whip Kit - The Disconnect Box & Whip Kit provides a safe and simple way to connect your outdoor condenser to your fuse box.
- Connecting Wire - This durable, insulated wire provides power to your indoor units from your outdoor condenser.
- Outdoor Condenser Plastic Pad (Optional) - This pad provides an even surface, free of debris, on which to place your outdoor condenser.
- Wall Bracket (Optional) - A simple and sturdy way to mount your outdoor condenser off of the ground.
This product requires two or more compatible indoor units for functionality. Daikin has firmly established themselves as a world leader in heating and cooling equipment manufacturing, and their ductless systems are no exception. This is a 3MXS24RMVJU outdoor condenser unit for use in a 3-zone system. This condenser supports three indoor units operating simultaneously, allowing you to build the ideal system type to fit your home's specific needs. A broad range of accessories are available to add to your system as well, which when combined with Daikin's extensive experience with building efficient units provides a solution to any home's heating and cooling needs.
Product Note
Each indoor unit will include any port adapters necessary for multi-zone installation. This product requires at least two compatible Daikin mini split indoor units and the following accessories for installation:
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
3MXS24RMVJU
Overview
Product Category
Mini Split System Components
General Information
Type
Outdoor Condenser
Product Line
MXS
Product Category
Mini Split System Components
Operating Mode
Operating Mode
Some products are only capable of cooling, while others can either heat or cool a space. Some products heat via "heat pump" technology while others use electric heating elements. Learn More
Heating and Cooling
Maximum Number of Zones
3
Multi-Zone Compatible
Yes
Refrigerant Type
R-410A
Installation Location
Outdoor
Performance
Cooling BTU
24000
Maximum Sound Level
Maximum Sound Level
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB. Learn More
54 dB
Low Ambient Heating
No
Minimum Outdoor Temperature for Heating
Minimum Outdoor Temperature for Heating
This is the lowest rated outdoor temperature for heating operation. Because heat pumps rely on heat available in outdoor air, the amount of heat they are able to supply decreases with outdoor temperatures. Learn More
5 F
Minimum Outdoor Temperature for Cooling
14 F
Electrical Data
Voltage
208/230 Volts
Phase
1
Frequency
60 Hz
Minimum Circuit Ampacity
21.9 Amps
Recommended Breaker Size
25 Amps
Dimensions
Maximum Line Length
230 Feet
Line Set A Liquid Connection
1/4 Inch
Line Set A Gas Connection
3/8 Inch
Line Set B Liquid Connection
1/4 Inch
Line Set B Gas Connection
1/2 Inch
Line Set C Liquid Connection
1/4 Inch
Line Set C Gas Connection
1/2 Inch
Product Height
29 Inches
Product Width
34 1/4 Inches
Product Depth
12 5/8 Inches
Product Weight
137 Pounds
Shipping Weight
147 Pounds
Certifications
ETL Listed
Yes
AHRI Certified
Yes
ISO Certified
Yes
Warranty Information
Parts Warranty
Parts Warranty
A warranty is a safeguard from defects in manufacturing and can vary in length and terms. Some manufacturers require registration for extended warranty benefits, be sure to check out features and the warranty document. To see the manufacturer's warranty statement, click on the Manuals tab. Learn More
5 Years
Compressor Warranty
7 Years
Reviews
(3)
Daikin 3MXS24RMVJU Reviews & Ratings
Great System
By Erik L
PROSPECT, Oregon
Purchased 07/20/2019 |
Review Posted 11/08/2019
I chose this unit for the warranty and reputation over other cheaper setups and have not been disappointed one bit. Works great (at least the heat part anyway, as it is winter)...can't wait for summer to enjoy the a/c.
Erik L Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, High Quality, warranty
I Recommend You Buy This Product!
By Vadzim L
Marysville, Washington
Purchased 09/23/2019 |
Review Posted 10/24/2019
This is a good product which keeps my house warm.
Vadzim L Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Quiet, Price, Light Weight, I'd Buy It Again
Great Unit
By Reid J
Lake Stevens, Washington
Purchased 08/19/2019 |
Review Posted 09/10/2019
This is a great unit I decided to go with the Daikin 2-4 zone and 3 head units for my house 1,100 sq ft 3 bed 2 bad. Daikin may not be as "high end" as the Mitsubishi but in my opinion specs for the price you are way ahead with Daikin. Clean looking unit and head units are nice as well easy to install.
Reid J Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
