Zoeller D284-0003 - 1HP Cast Iron Sewage Pump (2") w/ Vertical Float Switch (230V)

Model:

284-0003

Write A Review
$1,136.00
Holiday Shipping Schedule
Holiday Schedule -
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 3-4 Weeks

Zoeller D284-0003 - 1HP Cast Iron Sewage Pump (2
Zoeller D284-0003 - 1HP Cast Iron Sewage Pump (2") w/ Vertical Float Switch (230V)
Model: 284-0003
$1,136.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Sewage Pump

GPH

10740 Gallons

Switch Type

Vertical

  • 230V Automatic Submersible Sewage / Ejector Pump
  • Ideal for average to above average sewage removal
  • Durable Cast Iron Design w/ Powder Coated Epoxy Finish
  • Provides a corrosion resistant switch case, base, motor & pump housing
  • 1 HP Thermally Protected PSC Motor w/ Auto-Reset (230V)
  • Oil-filled and hermetically sealed to prevent overheating
  • Reliable, Float Operated, (NEMA 6) Vertical Mechanical Switch
  • Provides an 'On' point of 15-1/4" and 'Off' point of 5-1/4"
  • Non-Clogging Cast Iron Vortex Impeller
  • Capable of passing 2" spherical solids
  • Carbon/Ceramic Rotary Face Shaft Seal w/ SS Wetted Parts
  • Assures maximum protection for extended pump life
  • 2" NPT Standard Discharge
  • Optional flange available for 3" discharge (Please Inquire)
  • 10' Power Cord
  • Industry Leading Quality Control - Pressure Tested After Assembly
  • UL listed cord with 3-prong plug
  • *Note* Max Operating 130F & 35' Shutoff Head
  • SS Screws, Guard, Handle, Arm & Seal To Minimize Corrosion
  • 3-Year Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

284-0003
specs product image PID-14657
General Information
Product Category
Sump Pump
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
8.9
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Float Type
Vertical Float
GPH @ 0 feet
10740
GPH @ 5 feet
10740
GPH @ 10 feet
9420
GPH @ 15 feet
7980
GPH @ 20 feet
6360
Discharge Port Size
2 Inch
Check Valve Included
No
Float On
15.25 Inches
Float Off
5.25 Inches
Manual Override
No
Submersible
Yes
Engine
Horsepower
1 hp
Overview
Product Category
Sump Pump
Weight
87 Pounds
Consumer Warranty
3 Years
Product Length
13.56 Inches
Product Width
10 Inches
Product Height
21.43 Inches
UPC
053514018580
Additional Model Numbers

D284, 284-0003
