Zoeller 189-0004 - E189 2 HP Cast Iron High Head Effluent Pump (230V - Non-Automatic)

Zoeller 189-0004 - E189 2 HP Cast Iron High Head Effluent Pump (230V - Non-Automatic)
Model: 189-0004
$1,068.00
Factory-Direct
Ships in 3 - 4 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Free ShippingNo Sales Tax* (Except IL)$1,068.00Buy Now
Free ShippingNo Sales Tax* (Except IL)$1,068.00Visit Site
No Sales Tax* (Except IL)$1,068.00Visit Site
Factory-Direct
Ships in 3 - 4 Weeks
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Free Shipping
Free Shipping
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Effluent Sumps Pumps
GPH
8700
Gallons
Switch Type
None
Features
Features
  • ***NON-AUTOMATIC - Requires Float Switch or Controller***
  • Zoeller High Head Flow-Mate Effluent Pump (230V)
  • For septic tank, low pressure pipe (LPP) & enhanced flow STEP systems
  • Durable Cast Iron Construction (Base, Pump & Motor Housing
  • Corrosion-resistant powder coated epoxy finish
  • 2 HP Thermally Protected PSC Motor (3450 RPM)
  • Oil-filled & hermetically sealed to prevent overheating w/ auto-reset
  • High Head Design (110' Shut-Off Head)
  • Can pump up to 960 GPH @ 100' head
  • Non-Clogging Bronze Vortex Impeller
  • Capable of passing 3/4" spherical solids
  • Carbon/Ceramic Shaft Seal & Upper/Lower Ball Bearings
  • Assures maximum protection for extended pump life
  • No Sheet Metal Parts To Rust Or Corrode
  • Stainless steel screws, guard, handle, arm and seal assembly
  • 1-1/2" NPT Discharge
  • Allows for easy connection to your discharge line
  • 20' Power Cord
  • UL Listed 3-wire neoprene cord and 230V plug
  • 1-Year Limited Warranty
Specifications
Motor
Voltage
230 Volt
Running Amps
17.1
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Engine
Horsepower
2 hp
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
No Switch
GPH @ 0 feet
8700
GPH @ 5 feet
8700
GPH @ 10 feet
8400
GPH @ 20 feet
7830
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Overview
Weight
87 Pounds
Product Width
12.75 Inches
Product Height
19.3 Inches
Consumer Warranty
1 Year
UPC
053514016333
Style
Effluent Sumps Pumps
GPH
8700
Gallons
Switch Type
None
Features
Features
  • ***NON-AUTOMATIC - Requires Float Switch or Controller***
  • Zoeller High Head Flow-Mate Effluent Pump (230V)
  • For septic tank, low pressure pipe (LPP) & enhanced flow STEP systems
  • Durable Cast Iron Construction (Base, Pump & Motor Housing
  • Corrosion-resistant powder coated epoxy finish
  • 2 HP Thermally Protected PSC Motor (3450 RPM)
  • Oil-filled & hermetically sealed to prevent overheating w/ auto-reset
  • High Head Design (110' Shut-Off Head)
  • Can pump up to 960 GPH @ 100' head
  • Non-Clogging Bronze Vortex Impeller
  • Capable of passing 3/4" spherical solids
  • Carbon/Ceramic Shaft Seal & Upper/Lower Ball Bearings
  • Assures maximum protection for extended pump life
  • No Sheet Metal Parts To Rust Or Corrode
  • Stainless steel screws, guard, handle, arm and seal assembly
  • 1-1/2" NPT Discharge
  • Allows for easy connection to your discharge line
  • 20' Power Cord
  • UL Listed 3-wire neoprene cord and 230V plug
  • 1-Year Limited Warranty
Specifications
Motor
Voltage
230 Volt
Running Amps
17.1
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Engine
Horsepower
2 hp
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
No Switch
GPH @ 0 feet
8700
GPH @ 5 feet
8700
GPH @ 10 feet
8400
GPH @ 20 feet
7830
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Overview
Weight
87 Pounds
Product Width
12.75 Inches
Product Height
19.3 Inches
Consumer Warranty
1 Year
UPC
053514016333
Product Specs
+
Specifications
Motor
Voltage
230 Volt
Running Amps
17.1
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Engine
Horsepower
2 hp
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
No Switch
GPH @ 0 feet
8700
GPH @ 5 feet
8700
GPH @ 10 feet
8400
GPH @ 20 feet
7830
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Overview
Weight
87 Pounds
Product Width
12.75 Inches
Product Height
19.3 Inches
Consumer Warranty
1 Year
UPC
053514016333
Reviews
+
This product has no reviews.
Be the first to voice your opinion on this Zoeller product.
Product Q&A
+
Be the first to ask a question.
Recommended Accessories
+
How-To Articles
+
Manuals
+


×
Zoeller 189-0004 - E189 2 HP Cast Iron High Head Effluent Pump (230V - Non-Automatic)
+
