Winco W105FPTOT-4 - 105 kW Tractor-Driven PTO Generator 3-Phase (120/208V)

Winco W105FPTOT-4 - 105 kW Tractor-Driven PTO Generator 3-Phase (120/208V)
Model: W105FPTOT-4
$10,200.00
Backordered
Estimated Availability March 05, 2018
Notify Me When In-Stock
Free Shipping &
Tax-Free (Except IL)
Free Lift Gate Service -
Add-Ons
Free ShippingNo Sales Tax* (Except IL)$10,200.00Buy Now
Free FreightNo Sales Tax* (Except IL)$10,200.00Visit Site
Backordered
Estimated Availability March 05, 2018
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
105,000
Rated Watts
Surge Watts
105,000
Starting Watts
Features
Features
  • This PTO provides 105kW/364 amps continuous power
  • This PTO generator requires 210hp to run
  • The PTO input speed is 1000 and generator speed is 1800 RPM
  • 100% Copper Windings
  • Brushless Revolving Field
  • Precision AVR Regulated voltage 1.5%
  • Heavy Duty construction
  • Grounding Ternimal
  • Full Power Anderson Style Receptacle (Includes Anderson Plug)
  • Mainline Circuit Breaker
  • Shielded PTO Shaft
  • Rodent Screen
  • Mounting Base
  • Sealed Ball Bearings
  • Speed Indictaor visible from tractor seat
Specifications
Plugs
NEMA L5-20R
NEMA 6-50R
Full Power Receptacle
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Surge Watts
105000 Watts
Rated Watts
105000 Watts
Rated Amps
364 Amps
Voltage Meter
Yes
Tractors HP
210 HP
PTO RPMs
1000 RPM
Grade Type
Professional
Plugs
NEMA L5-20R
1
NEMA 6-50R
1
Full Power Receptacle
1
Overview
Made in USA
Yes
Weight
1216 Pounds
Product Style
PTO Generator
Product Length
42.2 Inches
Product Width
20.8 Inches
Product Height
30.2 Inches
Consumer Warranty
3 Years
Grade
Style
Run Watts
105,000
Rated Watts
Surge Watts
105,000
Starting Watts
Features
Features
  • This PTO provides 105kW/364 amps continuous power
  • This PTO generator requires 210hp to run
  • The PTO input speed is 1000 and generator speed is 1800 RPM
  • 100% Copper Windings
  • Brushless Revolving Field
  • Precision AVR Regulated voltage 1.5%
  • Heavy Duty construction
  • Grounding Ternimal
  • Full Power Anderson Style Receptacle (Includes Anderson Plug)
  • Mainline Circuit Breaker
  • Shielded PTO Shaft
  • Rodent Screen
  • Mounting Base
  • Sealed Ball Bearings
  • Speed Indictaor visible from tractor seat
Specifications
Plugs
NEMA L5-20R
NEMA 6-50R
Full Power Receptacle
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Surge Watts
105000 Watts
Rated Watts
105000 Watts
Rated Amps
364 Amps
Voltage Meter
Yes
Tractors HP
210 HP
PTO RPMs
1000 RPM
Grade Type
Professional
Plugs
NEMA L5-20R
1
NEMA 6-50R
1
Full Power Receptacle
1
Overview
Made in USA
Yes
Weight
1216 Pounds
Product Style
PTO Generator
Product Length
42.2 Inches
Product Width
20.8 Inches
Product Height
30.2 Inches
Consumer Warranty
3 Years
Product Specs
+
Specifications
Plugs
NEMA L5-20R
NEMA 6-50R
Full Power Receptacle
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Surge Watts
105000 Watts
Rated Watts
105000 Watts
Rated Amps
364 Amps
Voltage Meter
Yes
Tractors HP
210 HP
PTO RPMs
1000 RPM
Grade Type
Professional
Plugs
NEMA L5-20R
1
NEMA 6-50R
1
Full Power Receptacle
1
Overview
Made in USA
Yes
Weight
1216 Pounds
Product Style
PTO Generator
Product Length
42.2 Inches
Product Width
20.8 Inches
Product Height
30.2 Inches
Consumer Warranty
3 Years
