Tsurumi LB-480A - 62.4 GPM (2") Automatic Submersible Utility Pump
Model:
LB-480A
Number of Reviews
(8)
Write A Review
Ask a Question

$533.00
Free Shipping
×
Free Shipping
*This product qualifies for
Free Shipping
anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
More On The Way
Estimated Availability February 07, 2023
Shipping to
60601
Update Shipping Details
Shipping Details
ZIP Code
Update
Free to Lower 48 States
Standard Rates to
Alaska
,
Hawaii
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Notify Me When In-Stock
Email Address
Remind Me
+
Available Add-Ons
Tsurumi LB-480A - 62.4 GPM (2") Automatic Submersible Utility Pump
Model: LB-480A
Number of Reviews
(8)
Ask a Question
$533.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share
+
Share This Product
Recommended Accessories
+
Expert Recommended Accessories
Selected by Jim, our Expert
Required Accessories
9
These accessories are required to properly setup/install this product.
Add All Required Accessories
Optional Accessories
10
Features
×
Inlet Size
N/A
Style
Utility
GPM
62.4 Gallons
Slimline Automatic Submersible Utility Pump w/ 2" Discharge
Allows pump to operate in spaces 8-3/4" diameter or larger
Molded Resin, Rubber Protected EL-1 Relay (Req. 4.5" - On)
No control panel/float, electrodes detect water to start pump
Internal timer eliminates frequent on/off in rough conditions
2/3-HP 6.1-Amp Motor (12.5-Amp Starting) w/ Thermal Protection
Continuous duty rated, capable of pumping up to 3744 GPH
Top Discharge Provides Maximum Motor Cooling Efficiency
Provides max motor cooling efficiency & extended dry run time
Urethane Semi-Vortex Impeller & Wear Plates
Designed for maximum durability & pump performance
Double Inside Mechanical Seal w/ Silicon Faces
Provides the longest operational life of any seal available
Oil Lifter
Provides lubrication of the seal faces
V-Ring Seal Design
Protects mechanical seal from abrasive particles
32' Power Cord
Great for outdoor applications
2-Year Limited Warranty
California residents see
Prop 65 WARNINGS
Show All Features
×
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to:
www.p65Warnings.ca.gov
Specifications
+
LB-480A
General Information
Product Category
Water Pump
Motor
Voltage
120 Volt
Running Amps
6.1
Power Cord Length
32 Feet
Pump
Gallons Per Minute
62.4 Gallons
Outlet Diameter
2 Inch
Mechanical Seal Material
Silicon Carbide
Housing Material
Thermoplastic
Impeller Material
Plastic
Solids Handling Size
.25 inch
Total Head Lift
39.5 Feet
Float Type
Electronic
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Silicon Carbide
Horsepower
0.66 hp
Overview
Product Category
Water Pump
Weight
30 Pounds
Consumer Warranty
2 Years
Product Width
8.75 Inches
Product Height
11.25 Inches
UPC
894787000380
Additional Model Numbers
LB480A, LB-480A
