Red Lion 1/2 HP Deep Well Submersible Pump (2-Wire 115V)

Red Lion 1/2 HP Deep Well Submersible Pump (2-Wire 115V)
Model: RL12G05-2W1V
$299.00
In-Stock
Ships Wednesday, Jan 24th
Free Shipping &
Tax-Free (Except IL)
In-Stock Free ShippingNo Sales Tax* (Except IL)$299.00Buy Now
In-Stock Free ShippingNo Sales Tax* (Except IL)$299.00Visit Site
No Sales Tax* (Except IL)$299.00Visit Site

(as of 06:52 CST - Details) Sales Tax Extra $356.81Visit Site
Sales Tax Extra $347.64Visit Site
In-Stock
Ships Wednesday, Jan 24th
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Free Shipping
Free Shipping
Expedited Shipping
Expedited Shipping
  • Product Description
  • 43
    Reviews
  • 6
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
N/A
Style
GPM
12
Gallons
Features
Features
  • 4" Submersible Deep Well Pump
  • Ideal for use with 4" I.D. or larger wells
  • Powered By Industry Standard Motor
  • Proven superior quality & performance ensuring quiet operation
  • Hex Rubber Bearing w/ Extra-Large Surface
  • Provides shaft stability and multiple flow channels
  • Keeps small particles such as sand away from bearing surfaces
  • Built-In Check Valve
  • Prevents back-flow and ensures system pressure
  • Built-In Suction Screen
  • Helps to prevent debris from clogging impellers
  • 1-1/4" NPT Thermoplastic Discharge Head
  • Provides full-flow performance without the risk of corrosion
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Engine
Continuous Operation
Yes
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
200 Feet
Maximum PSI
80
Submersible
Yes
Overview
Made in USA
No
Weight
21 Pounds
Consumer Warranty
3 Years
UPC
010121141773

Inlet Size
N/A
Style
GPM
12
Gallons
Features
Features
  • 4" Submersible Deep Well Pump
  • Ideal for use with 4" I.D. or larger wells
  • Powered By Industry Standard Motor
  • Proven superior quality & performance ensuring quiet operation
  • Hex Rubber Bearing w/ Extra-Large Surface
  • Provides shaft stability and multiple flow channels
  • Keeps small particles such as sand away from bearing surfaces
  • Built-In Check Valve
  • Prevents back-flow and ensures system pressure
  • Built-In Suction Screen
  • Helps to prevent debris from clogging impellers
  • 1-1/4" NPT Thermoplastic Discharge Head
  • Provides full-flow performance without the risk of corrosion
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Engine
Continuous Operation
Yes
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
200 Feet
Maximum PSI
80
Submersible
Yes
Overview
Made in USA
No
Weight
21 Pounds
Consumer Warranty
3 Years
UPC
010121141773
Product Specs
+
Specifications
Motor
Voltage
120 Volt
Wire
2-Wire
Engine
Continuous Operation
Yes
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
200 Feet
Maximum PSI
80
Submersible
Yes
Overview
Made in USA
No
Weight
21 Pounds
Consumer Warranty
3 Years
UPC
010121141773
Reviews
(43)
+
Red Lion RL12G05-2W1V Reviews & Ratings
100% of Reviewers Recommend This Product
Product Q&A
(6)
+
In have 4 inch ID pvc well casing ..your product description says it will fit. What is the width of the pump?
Vince
from Indiana
June 16, 2016
Read Response +
Answer
The width of these pumps average 3.90" and WILL fit inside a 4" well casing.
If you have any other questions, please let me know.
Hide Response -
I plan to replace a 30 yer old pump that is at 200 ft. and lower the new pump to 250 ft in a 400 ft deep well. Will I need to a check valve mid way up as well as at the well head?
Ken G
from California
July 27, 2015
Read Response +
Answer
Most submersible deep well pumps include a built-in check valve at the discharge port of the pump and It is recommended that additional spring loaded in-line check valves be installed in the drop pipe @ 200ft intervals only.
Hide Response -
Does wiring come with the pump
Dwight B
from Louisiana
June 11, 2015
Read Response +
Answer
The Red Lion deep well pumps include 12" - 18" of wire and a waterproof splice kit and instructions. All other wiring does need to be supplied by you or your installer.
Hide Response -
Does this pump require a separate control box?
Robert B
from Alaska
November 03, 2014
Read Response +
Answer
2-wire deep well submersible pumps do NOT require a separate control box as the pump starting component (start capacitor, relay and overload) are located inside the pump, not inside the control box. 3-wire pumps are the only pumps that require a separate control box as the pump starting components are then located inside the control box.
Hide Response -
Does the Red Lion RL12G07-2W2V have thermal over load protection
Clark
from Kentucky
February 05, 2014
Read Response +
Answer
The Red Lion RL12G07-2W2V, like all the Red Lion deep well pumps, do include thermal overload protection.
Hide Response -
Does this pump have a grounding wire beside the two hot wires?
Dan S
from New York
August 17, 2013
Read Response +
Answer
Thank you for your interest in Water Pumps Direct. The Red Lion model RL12G07-2W2V, like any other 2-Wire deep well pump, would have two line voltage wires and one ground wire so you would have three wires total.
Hide Response -
