Multiquip ST41230 - 423 GPM (4") Submersible Utility Pump (230V - 3-Phase)

Multiquip ST41230 - 423 GPM (4") Submersible Utility Pump (230V - 3-Phase)
Model: ST41230
$3,397.00
Factory-Direct
Ships in 7-14 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping
Free ShippingNo Sales Tax* (Except IL)$3,397.00Buy Now
Free FreightNo Sales Tax* (Except IL)$3,397.00Visit Site
Factory-Direct
Ships in 7-14 Business Days
Free Freight
Free Freight
*We currently CANNOT ship this product to California, Florida, Louisiana, Massachusetts, Maryland, New York, Pennsylvania or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
N/A
Style
Utility Pumps
GPM
423
Gallons
Inlet Size
N/A
Style
Utility
GPM
423 Gallons
Features
Features
  • Multiquip 4" Discharge Industrial Submersible Pump
  • Ideal for supporting tough utility and municipal jobs
  • 10-HP 230V 3-Phase Motor
  • Thermal/over current motor protection for added safety
  • Stainless Steel Outer Casing
  • Designed to resist corrosion and keep pump running cool
  • Double Mechanical Pump Seals
  • Oil-filled design provides lubrication when running dry
  • High Chrome Impeller w/ Easy Clean Out
  • Allows the pump to move up to 25380 GPH
  • Heat-Treated 410 Stainless Steel Shaft
  • Designed to extend the pump life
  • 304 Stainless Steel Suction Strainer
  • Allows the pump to pas solids up to .5"
  • 33' Power Cord w/ Strain-Relief
  • Plenty of cord for municipal applications
  • *Note* Requires (CB1269) Control Box (Sold Separately)
  • Provide safe operations and safety shutdowns
  • Allows for float switch connections for automatic operation
Specifications
Motor
Voltage
230 Volt 3-Phase
Pump
Gallons Per Minute
423 Gallons
Outlet Diameter
4"
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
.5 inch
Total Head Lift
138 Feet
Submersible
Yes
Engine
Horsepower
10 hp
Accessories
Control Box
Sold Separately
Transport Handle
Yes
Overview
Weight
205 Pounds
Product Width
12.5 Inches
Product Height
32 Inches
Consumer Warranty
1 Year

Inlet Size
N/A
Style
Utility Pumps
GPM
423
Gallons
Inlet Size
N/A
Style
Utility
GPM
423 Gallons
Features
Features
  • Multiquip 4" Discharge Industrial Submersible Pump
  • Ideal for supporting tough utility and municipal jobs
  • 10-HP 230V 3-Phase Motor
  • Thermal/over current motor protection for added safety
  • Stainless Steel Outer Casing
  • Designed to resist corrosion and keep pump running cool
  • Double Mechanical Pump Seals
  • Oil-filled design provides lubrication when running dry
  • High Chrome Impeller w/ Easy Clean Out
  • Allows the pump to move up to 25380 GPH
  • Heat-Treated 410 Stainless Steel Shaft
  • Designed to extend the pump life
  • 304 Stainless Steel Suction Strainer
  • Allows the pump to pas solids up to .5"
  • 33' Power Cord w/ Strain-Relief
  • Plenty of cord for municipal applications
  • *Note* Requires (CB1269) Control Box (Sold Separately)
  • Provide safe operations and safety shutdowns
  • Allows for float switch connections for automatic operation
Specifications
Motor
Voltage
230 Volt 3-Phase
Pump
Gallons Per Minute
423 Gallons
Outlet Diameter
4"
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
.5 inch
Total Head Lift
138 Feet
Submersible
Yes
Engine
Horsepower
10 hp
Accessories
Control Box
Sold Separately
Transport Handle
Yes
Overview
Weight
205 Pounds
Product Width
12.5 Inches
Product Height
32 Inches
Consumer Warranty
1 Year
Product Specs
+
Specifications
Motor
Voltage
230 Volt 3-Phase
Pump
Gallons Per Minute
423 Gallons
Outlet Diameter
4"
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
.5 inch
Total Head Lift
138 Feet
Submersible
Yes
Engine
Horsepower
10 hp
Accessories
Control Box
Sold Separately
Transport Handle
Yes
Overview
Weight
205 Pounds
Product Width
12.5 Inches
Product Height
32 Inches
Consumer Warranty
1 Year
