MEGA 5-HP 60-Gallon Single-Stage Air Compressor (208/230V 1-Phase - 150 PSI)

Model:

MP-6560VB

Write A Review
$1,199.99
Holiday Shipping Schedule
Holiday Schedule -
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days

MEGA 5-HP 60-Gallon Single-Stage Air Compressor (208/230V 1-Phase - 150 PSI)
MEGA 5-HP 60-Gallon Single-Stage Air Compressor (208/230V 1-Phase - 150 PSI)
Model: MP-6560VB
$1,199.99
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Power Equipment Direct expert image
Expert Recommended Accessories Selected by Joshua, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Consumer

Style

Single Stage 1-Phase

CFM

18

Tank Size

60

  • MEGA Single-Stage Air Compressor
  • Perfect for DIY projects to the professional air compressor user
  • Heavy-Duty 5-HP Induction Motor
  • 208/230-volt single-phase motor
  • Provides maximum performance and efficiency
  • Delivers 18 CFM @ 90 PSI: Max 150 PSI
  • Plenty of power to run a wide range of air tools
  • Tackle airbrushing, drilling, sanding and bolting/wrenching
  • Cast Iron V-Twin Oil Lubricated Pump
  • Thermally stable cast iron cylinder body
  • Aluminum head and machine cast iron valve plate
  • Aluminum pump head helps dissipate heat for longer pump life
  • "W" Design
  • Minimizes vibration, improves cooling, extends compressor life
  • One-Piece Cast Iron Crankcase
  • Durable automotive-style ball bearings
  • Stainless steel reed valves for increased volumetric efficiency
  • 60-Gallon Vertical Tank
  • Fully enclosed belt guard protects you and the belt
  • Easy-access manual drain simplifies routine maintenance
  • Easy Viewing Oil Sight Glass On Pump
  • Easily check compressors pump oil level
  • Conveniently accessible oil fill for fast maintenance
  • 1-Year Limited Manufacturer Warranty
  • Protect your investment
  • Shipped with 100% full synthetic air compressor
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

MP-6560VB
specs product image PID-118700
General Information
Product Category
Air Compressor - Stationary
Engine
HP
5
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
18
Recommended Breaker
30 Amp Breaker
Pump
CFM
18
CFM Rated @
90 PSI
Pump Material
Cast Iron w/ Aluminum Head
Max PSI
150 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Included
Yes
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
418 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
28 Inches
Product Width
32 Inches
Product Height
74 Inches
Power Type
Electric
UPC
376204971492
