Little Giant W12G05S7-22P - 1/2 HP 12 GPM Deep Well Submersible Pump (2-Wire 230V)

Little Giant W12G05S7-22P - 1/2 HP 12 GPM Deep Well Submersible Pump (2-Wire 230V)
Model: 558565
$449.99
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Free ShippingNo Sales Tax* (Except IL)$449.99Buy Now
Free ShippingNo Sales Tax* (Except IL)$449.99Visit Site
No Sales Tax* (Except IL)$449.99Visit Site
Factory-Direct
Ships in 2-5 Business Days
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Free Shipping
Free Shipping
  • Product Description
  • Reviews
  • 2
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Inlet Size
N/A
Style
GPM
12
Gallons
Features
Features
  • 4" Submersible Deep Well Pump (2-Wire 230V)
  • Ideal for use with 4" I.D. or larger wells
  • Powered By Industry Standard Franklin Electric Motor
  • Proven superior quality & performance ensuring quiet operation
  • Hex Rubber Bearing w/ Extra-Large Surface
  • Provides shaft stability and multiple flow channels
  • Keeps small particles such as sand away from bearing surfaces
  • Built-In Flomatic™ Check Valve
  • Prevents backflow and ensures system pressure
  • Removable Suction Screen
  • Helps to prevent debris from clogging impellers
  • Celcon® Disk
  • Provides close tolerances for increased performance
  • Ceramic Bearing Sleeve & Stainless steel Up-Thrust Washer
  • Prevents excessive wear and provides added durability
  • 1-1/4" NPT Thermoplastic Discharge Head
  • Provides full-flow performance without the risk of corrosion
  • 2-Year Warranty
  • *Note* Installation Checklist Can Be Found On Spec Tab
Specifications
Motor
Voltage
240 Volt
Wire
2-Wire
Engine
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Overview
Weight
24 Pounds
Product Length
22.29 Inches
Product Width
3.9 Inches
Consumer Warranty
2 Years
UPC
010121118508

Inlet Size
N/A
Style
GPM
12
Gallons
Features
Features
  • 4" Submersible Deep Well Pump (2-Wire 230V)
  • Ideal for use with 4" I.D. or larger wells
  • Powered By Industry Standard Franklin Electric Motor
  • Proven superior quality & performance ensuring quiet operation
  • Hex Rubber Bearing w/ Extra-Large Surface
  • Provides shaft stability and multiple flow channels
  • Keeps small particles such as sand away from bearing surfaces
  • Built-In Flomatic™ Check Valve
  • Prevents backflow and ensures system pressure
  • Removable Suction Screen
  • Helps to prevent debris from clogging impellers
  • Celcon® Disk
  • Provides close tolerances for increased performance
  • Ceramic Bearing Sleeve & Stainless steel Up-Thrust Washer
  • Prevents excessive wear and provides added durability
  • 1-1/4" NPT Thermoplastic Discharge Head
  • Provides full-flow performance without the risk of corrosion
  • 2-Year Warranty
  • *Note* Installation Checklist Can Be Found On Spec Tab
Specifications
Motor
Voltage
240 Volt
Wire
2-Wire
Engine
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Overview
Weight
24 Pounds
Product Length
22.29 Inches
Product Width
3.9 Inches
Consumer Warranty
2 Years
UPC
010121118508
Product Specs
+
Specifications
Motor
Voltage
240 Volt
Wire
2-Wire
Engine
Horsepower
0.5 hp
Pump
Gallons Per Minute
12 Gallons
Outlet Diameter
1-1/4"
Housing Material
Stainless Steel
Impeller Material
Plastic
Total Head Lift
231 Feet
Submersible
Yes
Overview
Weight
24 Pounds
Product Length
22.29 Inches
Product Width
3.9 Inches
Consumer Warranty
2 Years
UPC
010121118508
Reviews
+
This product has no reviews.
Be the first to voice your opinion on this Little Giant product.
Product Q&A
(2)
+
In have 4 inch ID pvc well casing ..your product description says it will fit. What is the width of the pump?
Vince
from Indiana
June 16, 2016
Read Response +
Answer
The width of these pumps average 3.90" and WILL fit inside a 4" well casing.
If you have any other questions, please let me know.
Hide Response -
what parts are involved with submersible pumps that can fail and breakdown or if it doesn't work you just have to replace the entire pump?
Sal
from New York
January 22, 2014
Read Response +
Answer
When it comes to 2-wire deep well submersible pumps, the pump starting controls are located inside the pump. Any of these components can fail and cause the pump to become inoperable. By installing a 3-wire pump, those components would be located inside a CONTROL BOX, making repairs much easier when failure of these components are the cause of your pump not operating. Of course if the pump has failed due to burnt motor windings or some other cause, would would still need to pull and replace the pump, but you would have a better understanding of the pump status when the pump starting components are above ground as opposed to 50-500 feet or more, below ground.
Hide Response -
