Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)

Model:

2-2LSW7505-2

Write a Review
$592.00
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping Details
*We currently CANNOT ship this product to California or any destination outside of the United States

Free Shipping$592.00Buy Now
Free Shipping$592.00Visit Site
Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)
Lancaster Pump 2LSW7505-2 - 3/4 HP 22 GPM Deep Well Submersible Pump w/ SS Disc & Motor Sup. (2-Wire 230V)
Model: 2-2LSW7505-2
$592.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

Inlet Size

N/A

Style

Deep Well

GPM

22 Gallons

  • SURVIVOR W-Series 22 GPM 4" Sub. Well Pump (2-Wire 230V)
  • For 4" I.D. or + Wells (<160'); 3-Wire Starting - No Control Box Required
  • 3/4 HP Lancaster HYDRO-FORCE Encapsulated Sub. Motor
  • Continuous duty rated, Induction run design w/ built-in starter
  • Stainless Steel Motor Casing & Splined Shaft End
  • Hermetically sealed, permanently lubricated, for greater heat exchange
  • Built-In Lighting Arrestors & Automatic Reset Overload
  • Provides surge and overhead protection for increased protection
  • 1.25" Stainless Steel Discharge Head, Motor & Cable Support
  • Superior strength & corrosion resistance for max life; replaceable CV
  • Balanced TeflonŽ Impregnated Thermoplastic Impellers
  • Reduces overall friction to maximize water flow
  • Fully-Enclosed Thermoplastic Diffusers & Stage Plates w/ SS Wear Surfaces
  • Each stage has separate comp. thrust washer for added protection
  • Heavy wall, High Quality SS Pump Casing & SS Intake Screen
  • Sized inside for perfect stage alignmen; wouldn't snap off during install
  • 3-Year Limited Warranty

Specifications

2-2LSW7505-2
Motor
Voltage
240 Volt
Running Amps
9.3
Wire
3-Wire
Pump
Gallons Per Minute
22 Gallons
Outlet Diameter
1-1/4"
Pump Head Material
Stainless Steel
Housing Material
Stainless Steel
Impeller Material
Plastic
Maximum PSI
65
Total Head Lift
160 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Horsepower
0.75 hp
Overview
Assembly Required
Yes
Weight
28.9 Pounds
Consumer Warranty
3 Years
Product Length
24.16 Inches
Product Width
3.81 Inches
