Kohler 14KW Composite Home Standby Generator

Kohler 14KW Composite Home Standby Generator
Model: 14RESA
$3,330.00
Backordered
Estimated Availability January 19, 2018
Notify Me When In-Stock
Free Shipping &
Tax-Free (Except IL)
Free Lift Gate Service -
Add-Ons

Free ShippingNo Sales Tax* (Except IL)$3,330.00Buy Now
Free FreightNo Sales Tax* (Except IL)$3,330.00Visit Site
Backordered
Estimated Availability January 19, 2018
Enter your ZIP Code below to see an estimated arrival time of delivery to your home or business.
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
  • Product Description
  • 10
    Reviews
  • 7
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
14,000
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Features
Features
  • Kohler Command PRO® OHV Engine
  • Meets emission regulations for U.S. EPA & California
  • Powerful and reliable engine with hydraulic valve lifters
  • Powerful Performance w/ PowerBoost™ Technology
  • Greater motor-starting ability for large electrical loads
  • Premium Power Quality (+/-1% Voltage Regulation _
  • Protects sophisticated electronics with low distortion (<5%THD)
  • Fast Response
  • Kohler™ generators restore power in as little as 10 seconds
  • New Silencer Reduces Sound Levels & Provides Quiet Operation
  • Maintains neighborhood solitude - approx 67 dB(A) at 7 m (23 ft)
  • New RDC2 Controller
  • Glare-resistant, 2-line 16-character display - No More Codes
  • Easily view ATS status via LED lights on controller
  • Optional OnCue Remote Monitoring System (Sold Separately)
  • Built-in Ethernet card, no hardware needed for OnCue
  • Exclusive 100% Corrosion-Proof Composite Enclosure
  • Will not rust - even in harsh seaside environments
  • Premium Warranty - 5-year/2,000-hour limited warranty
  • Transfer Switch (Sold Separately) & Group 51 Bat. (Not Included)
Specifications
Engine
Engine Brand
Kohler
CC
725 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
14000 Watts
Rated Watts
14000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
12000 Watts
LP Power Capacity
14000 Watts
NG Fuel Consumption @ 50% Load
124 ft³/hr
NG Fuel Consumption @ 100% Load
193 ft³/hr
LP Fuel Consumption @ 50% Load
1.8 gallons/hr
LP Fuel Consumption @ 100% Load
2.4 gallons/hr
Rated Amps
58 Amps
Decibel Rating @ 7m
63 Test (67 Run) dbA
Transfer Switch
Automatic (Not Included)
Enclosure
Composite
Battery
Not Included (500 CCA)
A/C Ton Rating
5-Tons
Mounting Pad
Composite (Included)
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Overview
Made in USA
Yes
Weight
410 Pounds
Product Style
Standby Generator
Product Length
48 Inches
Product Width
26.2 Inches
Product Height
29 Inches
Consumer Warranty
5 Years
Commercial Warranty
5 Years
UPC
650531125378
Grade
Style
Run Watts
14,000
Rated Watts
Voltage
120/240 Single-Phase
Fuel
Engine
Features
Features
  • Kohler Command PRO® OHV Engine
  • Meets emission regulations for U.S. EPA & California
  • Powerful and reliable engine with hydraulic valve lifters
  • Powerful Performance w/ PowerBoost™ Technology
  • Greater motor-starting ability for large electrical loads
  • Premium Power Quality (+/-1% Voltage Regulation _
  • Protects sophisticated electronics with low distortion (<5%THD)
  • Fast Response
  • Kohler™ generators restore power in as little as 10 seconds
  • New Silencer Reduces Sound Levels & Provides Quiet Operation
  • Maintains neighborhood solitude - approx 67 dB(A) at 7 m (23 ft)
  • New RDC2 Controller
  • Glare-resistant, 2-line 16-character display - No More Codes
  • Easily view ATS status via LED lights on controller
  • Optional OnCue Remote Monitoring System (Sold Separately)
  • Built-in Ethernet card, no hardware needed for OnCue
  • Exclusive 100% Corrosion-Proof Composite Enclosure
  • Will not rust - even in harsh seaside environments
  • Premium Warranty - 5-year/2,000-hour limited warranty
  • Transfer Switch (Sold Separately) & Group 51 Bat. (Not Included)
Specifications
Engine
Engine Brand
Kohler
CC
725 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
14000 Watts
Rated Watts
14000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
12000 Watts
LP Power Capacity
14000 Watts
NG Fuel Consumption @ 50% Load
124 ft³/hr
NG Fuel Consumption @ 100% Load
193 ft³/hr
LP Fuel Consumption @ 50% Load
1.8 gallons/hr
LP Fuel Consumption @ 100% Load
2.4 gallons/hr
Rated Amps
58 Amps
Decibel Rating @ 7m
63 Test (67 Run) dbA
Transfer Switch
Automatic (Not Included)
Enclosure
Composite
Battery
Not Included (500 CCA)
A/C Ton Rating
5-Tons
Mounting Pad
Composite (Included)
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Overview
Made in USA
Yes
Weight
410 Pounds
Product Style
Standby Generator
Product Length
48 Inches
Product Width
26.2 Inches
Product Height
29 Inches
Consumer Warranty
5 Years
Commercial Warranty
5 Years
UPC
650531125378
Product Specs
+
Specifications
Engine
Engine Brand
Kohler
CC
725 CC
Consumer Engine Warranty
5 Years
Commercial Engine Warranty
5 Years
Engine RPM
3600 RPM
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Surge Watts
14000 Watts
Rated Watts
14000 Watts
Fuel Type
LP/Natural Gas
NG Power Capacity
12000 Watts
LP Power Capacity
14000 Watts
NG Fuel Consumption @ 50% Load
124 ft³/hr
NG Fuel Consumption @ 100% Load
193 ft³/hr
LP Fuel Consumption @ 50% Load
1.8 gallons/hr
LP Fuel Consumption @ 100% Load
2.4 gallons/hr
Rated Amps
58 Amps
Decibel Rating @ 7m
63 Test (67 Run) dbA
Transfer Switch
Automatic (Not Included)
Enclosure
Composite
Battery
Not Included (500 CCA)
A/C Ton Rating
5-Tons
Mounting Pad
Composite (Included)
Cooling System
Air Cooled
UL Listed
Yes
Grade Type
Emergency
Overview
Made in USA
Yes
Weight
410 Pounds
Product Style
Standby Generator
Product Length
48 Inches
Product Width
26.2 Inches
Product Height
29 Inches
Consumer Warranty
5 Years
Commercial Warranty
5 Years
UPC
650531125378
Reviews
(10)
+
Kohler 14RESA Reviews & Ratings
67% of Reviewers Recommend This Product
Product Q&A
(7)
+
I have a 9165 watt solar system which reverse meters to the grid. If the power is off, I have no power. Will one of the natural gas backup generators work with my system, or does the solar add complications?
Erik Johnson
from Colorado
December 16, 2013
Read Response +
Answer
Having multiple power sources can make things very complicated. However, we do offer two models of generators which can be turned on and off by your solar systems inverter system.

Generac's EcoGen model 5818 is specifically designed for use with alternative power options such as solar and wind and comes with a 3 year warranty......

Generac EcoGen Model 5818

Kohler offers their 14kW home standby generator capable for use with solar systems but they only offer an 18 month warranty as they are not specifically designed for this type of application. The generators internal controller can be adjusted to accept a 2 wire start from your inverter system.

Kohler 14kW Model 14RESA

We do recommend consulting with a local installer as your application can have some special parameters and installation requirements. They will also be familiar with your local code requirements so installation is done properly.
Hide Response -
What size gas supply pipe is needed from tank to generator?
Richard Evans
from Pennsylvania
July 20, 2013
Read Response +
Answer
Fuel pipe size is based on the distance from the fuel source and for the Kohler models the recommended pipe size and max distances are listed in the installation guide and in the Kohler spec sheet....

Kohler Spec Sheet
Hide Response -
Will the Kohler 14kw propane, work with my Nexus 200 amp smart switch?
Rick
from Virginia
December 30, 2012
Read Response +
Answer
No, you can only use a Kohler switch with a Kohler generator. If you want the same load shed capabilities you will need to purchase the Kohler Load Control Module along with the transfer switch.

If you currently have a 200A Generac Nexus switch you can only go with a Generac generator due to the wiring and how they are controlled.

Hide Response -
How does the warranty work? Does it have to be installed by a Kohler certified dealer for the warranty work?
Franz Gerster
from New York
December 13, 2012
Read Response +
Answer
Kohler does not require a Kohler certified installer only a minimum would be a certified electrician.

When a Kohler installer does the installation and start-up the warranty starts the day he starts the unit.

When a certified electrician installs and starts the unit the warranty starts the day the unit was shipped from the factory.

All service and warranty work must be completed by an authorized Kohler service technician.

Hide Response -
What would the fuel consumption be for the 14kW? Assuming a 200 gal LP tank, circuit load: 1 refrigerator, 1 microwave 1300 watts, and 4 small lighting circuits.
Bill Borresen
from Georgia
September 27, 2012
Read Response +
Answer
The posted fuel consumption of the 14kW Kohler home standby generator is:

1.8 Gallons/Hr when running at 50% load....2.3 Gallons/Hr at Full Load

The fuel consumption will vary depending on the actual load on the generator and you will need to have a certified electrician calculate your loads based on the starting amperage of the equipment you are intending on running.

Note: Tank size does not determine the fuel consumption of the generator, only the load on the generator.
Hide Response -
Most of our outages are in summer with a 3-ton AC running. Would this unit handle that plus a fridge & freezer, etc?
Max Tappen
from Ohio
July 01, 2012
Read Response +
Answer
It would be close when you are adding items to the mix. I would recommend getting the Kohler load manager so it can load shed the AC when it first starts while letting everything else start and get past its starting loads.

With this model generator you will need to get a transfer switch and if you are looking to do whole house the following switch would be recommended if you have 200A electrical service which you would need to verify with your installing electrician.

Kohler RXT 200A SE Rated Switch

Kohler Load Control Module
Hide Response -
Hi Jim, What is the difference between the 20resl and 20resal? I don't see the composite pad on this unit 20resal? Thanks, Steve
Steve
from New Jersey
February 21, 2012
Read Response +
Answer
The new "A" version has the following features added:
** New Controller - RDC2/DC2
- New display readable in direct sunlight, 2 lines, 16 characters per line, no more codes.
- Built-In 2.5A battery charger using 120 VAC allowing deletion of the separate 6A battery charger
- Includes Ethernet Board, so no hardware required to be installed for OnCue
- RDC2 has built-in LED's on controller overlay to view status of RXT transfer switch and source availability while standing at the genset
- Real Time Clock - Allows setting of Exercise for any time and day you want
- Internal protection, no controller fuses to service
- Controller is fully potted for protection against snow and moisture

** New Silencer design to reduce sound levels
- 14RESA sound level during exercise is 63 dBA, and 67 dBA during normal operation
- 20RESA sound level during exercise is 64 dBA, and 69 dBA during normal operation

The composite pad is the same color as the entire unit and already attached to the bottom of the generator.
Hide Response -
