Industrial Air 5.7-HP 80-Gallon Single-Stage Air Compressor
Model: ILA5148080
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews(2)
Write a Review
$1,409.99
Free Shipping
Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 7-14 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
  • Lift Gate Service Available - $75.00 Service Charge Learn More
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Available Add-Ons
+$75.00
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Free Shipping$1,409.99Buy Now
Free Freight$1,409.99Visit Site
Share
  • Product Description
  • 2
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Consumer
Style
Single Stage 1-Phase
CFM
18.1
CFM Rated @ 90 PSI
Tank Size
80
Gallons
Grade
Consumer
CFM
18.1 CFM Rated @ 90 PSI
Tank Size
80 Gallons
Features
Features
  • High Air Flow Single-Stage Compressor
  • Produces 18 CFM @ 90 PSI to run many different air tools
  • Cast Iron 3 Cylinder Pump
  • Durable, one piece cast-iron crankcase & full cylinder body
  • TOPSŪ Motor (Thermal Overload Protection System)
  • Protects the motor from voltage fluctuations
  • Oil Lubricated
  • Swedish stainless steel flex leaf valves for optimum performance
  • Shipped with synthetic oil for best performance & long pump life
  • Easy fill access & oil sight glass make maintenance simple
  • 16" Balanced Cast Iron Flywheel
  • Belt drive is smoother & quieter than direct-drive units
  • Large Intake Filter/Silencer
  • Provides good air flow & reduces noise
  • Large Capacity 80 Gallon ASME Air Receiver
  • Longer run times on air tools such as ratchets, impacts, etc.
  • Maximum pressure 155 PSI
  • Factory Warranty
  • 1 year for residential use; 90 days for commercial use
Specifications
Engine
HP
5.5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
18.1
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
410 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
90 Days
Product Length
37 Inches
Product Width
29 Inches
Product Height
76 Inches
Power Type
Electric
UPC
846212001585
Grade
Consumer
Style
Single Stage 1-Phase
CFM
18.1
CFM Rated @ 90 PSI
Tank Size
80
Gallons
Grade
Consumer
CFM
18.1 CFM Rated @ 90 PSI
Tank Size
80 Gallons
Features
Features
  • High Air Flow Single-Stage Compressor
  • Produces 18 CFM @ 90 PSI to run many different air tools
  • Cast Iron 3 Cylinder Pump
  • Durable, one piece cast-iron crankcase & full cylinder body
  • TOPSŪ Motor (Thermal Overload Protection System)
  • Protects the motor from voltage fluctuations
  • Oil Lubricated
  • Swedish stainless steel flex leaf valves for optimum performance
  • Shipped with synthetic oil for best performance & long pump life
  • Easy fill access & oil sight glass make maintenance simple
  • 16" Balanced Cast Iron Flywheel
  • Belt drive is smoother & quieter than direct-drive units
  • Large Intake Filter/Silencer
  • Provides good air flow & reduces noise
  • Large Capacity 80 Gallon ASME Air Receiver
  • Longer run times on air tools such as ratchets, impacts, etc.
  • Maximum pressure 155 PSI
  • Factory Warranty
  • 1 year for residential use; 90 days for commercial use
Specifications
Engine
HP
5.5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
18.1
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
410 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
90 Days
Product Length
37 Inches
Product Width
29 Inches
Product Height
76 Inches
Power Type
Electric
UPC
846212001585
Product Specs
+
Specifications
Engine
HP
5.5
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Pump
CFM
18.1
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
410 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
90 Days
Product Length
37 Inches
Product Width
29 Inches
Product Height
76 Inches
Power Type
Electric
UPC
846212001585
