Industrial Air 4.7-HP 80-Gallon (Belt Drive) Hi-Flo Single Stage Air Compressor (230V 1-Phase) w/ No Control Panel
Model: ILA4708065.01
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$1,139.99
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
  • Lift Gate Service Available - $75.00 Service Charge Learn More
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States

Available Add-Ons
+$75.00
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Free Shipping$1,139.99Buy Now
Free Freight$1,139.99Visit Site
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Consumer
Style
Single Stage 1-Phase
CFM
14
CFM Rated @ 90 PSI
Tank Size
80
Gallons
Grade
Consumer
CFM
14 CFM Rated @ 90 PSI
Tank Size
80 Gallons
Features
Features
  • Heavy Duty Compressor With No Control Panel
  • Designed for commercial users to plumb with their own controls
  • High air flow, single stage unit for industrial & commercial use
  • Cast Iron 3 Cylinder Pump
  • Oil lubricated & sight glass for smooth operation & maintenance
  • Delivers 16.1 CFM's @ 40 PSI & 14 CFM's @ 90 PSI
  • 155 PSI max pressure for optimum tool performance
  • Large Capacity 80 Gallon Air Receiver
  • More air for longer run times; ASME approved for safety
  • Easily powers ratchets, impacts, spray guns, hammers, etc.
  • Shipped With Synthetic Oil
  • Provides optimum performance & long pump life
  • Vertical Tank
  • 31.5L x 34.75W x 77H takes up less floor space
  • Factory Warranty
  • 1 year residential use; 90 days commercial use
  • CSA certification provide peace of mind
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
4
Pump
CFM
14
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
354 Pounds
Certification
CSA, ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31.5 Inches
Product Width
34.75 Inches
Product Height
77 Inches
Power Type
Electric
UPC
846212005750
Grade
Consumer
Style
Single Stage 1-Phase
CFM
14
CFM Rated @ 90 PSI
Tank Size
80
Gallons
Grade
Consumer
CFM
14 CFM Rated @ 90 PSI
Tank Size
80 Gallons
Features
Features
  • Heavy Duty Compressor With No Control Panel
  • Designed for commercial users to plumb with their own controls
  • High air flow, single stage unit for industrial & commercial use
  • Cast Iron 3 Cylinder Pump
  • Oil lubricated & sight glass for smooth operation & maintenance
  • Delivers 16.1 CFM's @ 40 PSI & 14 CFM's @ 90 PSI
  • 155 PSI max pressure for optimum tool performance
  • Large Capacity 80 Gallon Air Receiver
  • More air for longer run times; ASME approved for safety
  • Easily powers ratchets, impacts, spray guns, hammers, etc.
  • Shipped With Synthetic Oil
  • Provides optimum performance & long pump life
  • Vertical Tank
  • 31.5L x 34.75W x 77H takes up less floor space
  • Factory Warranty
  • 1 year residential use; 90 days commercial use
  • CSA certification provide peace of mind
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
4
Pump
CFM
14
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
354 Pounds
Certification
CSA, ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31.5 Inches
Product Width
34.75 Inches
Product Height
77 Inches
Power Type
Electric
UPC
846212005750
Product Specs
+
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
4
Pump
CFM
14
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
155 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Tank
Tank Size
80 Gallons
Tank Outlet
3/8 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
354 Pounds
Certification
CSA, ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
31.5 Inches
Product Width
34.75 Inches
Product Height
77 Inches
Power Type
Electric
UPC
846212005750
