Honda WSP100AA - 150 GPM (2") Submersible Trash Pump w/ Float Switch
Model: WSP100AA
+
Share This Product
-
Product Description
-
26Reviews
-
6Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Inlet Size
N/A
Style
GPM
150
Gallons
Inlet Size
N/A
Style
Trash
GPM
150 Gallons
Features
Features
- Submersible Trash Pump
- Easily handles leaves, debris, and solids up to 2"
- 1-HP 11.1-Amp Motor (47-Amp Starting)
- Continuous duty rated, capable of pumping 9000 GPH @ 0'
- Stainless Steel Casing
- Lightweight & durable design resists corrosion
- Built-In Thermal Protection w/ Automatic Reset
- Turns off the power supply in case of overload
- Non-Mercury Float Switch
- Provides reliable automatic operation
- Single Channel Stainless Steel Impeller
- Heavy duty design built to pass solids
- Tandem Mechanical Carbon/Ceramic Seals
- Extends the useful life of the pump
- 25' Cord
- Heavy duty design built to withstand the elements
- 1-Year Residential & Commercial Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
11.1
Power Cord Length
25 Feet
Pump
Gallons Per Minute
150 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Ceramic Carbon
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
2 inch
Handles Solids
Yes
Maximum PSI
18
Total Head Lift
42 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Ceramic Carbon
Horsepower
1 hp
Accessories
Float Switch
Yes
Overview
Weight
41 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Width
9 Inches
Product Height
22.8 Inches
UPC
786102002516
Additional Model Numbers
WSP100, WSP100AA
Inlet Size
N/A
Style
GPM
150
Gallons
Inlet Size
N/A
Style
Trash
GPM
150 Gallons
Features
Features
- Submersible Trash Pump
- Easily handles leaves, debris, and solids up to 2"
- 1-HP 11.1-Amp Motor (47-Amp Starting)
- Continuous duty rated, capable of pumping 9000 GPH @ 0'
- Stainless Steel Casing
- Lightweight & durable design resists corrosion
- Built-In Thermal Protection w/ Automatic Reset
- Turns off the power supply in case of overload
- Non-Mercury Float Switch
- Provides reliable automatic operation
- Single Channel Stainless Steel Impeller
- Heavy duty design built to pass solids
- Tandem Mechanical Carbon/Ceramic Seals
- Extends the useful life of the pump
- 25' Cord
- Heavy duty design built to withstand the elements
- 1-Year Residential & Commercial Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
11.1
Power Cord Length
25 Feet
Pump
Gallons Per Minute
150 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Ceramic Carbon
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
2 inch
Handles Solids
Yes
Maximum PSI
18
Total Head Lift
42 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Ceramic Carbon
Horsepower
1 hp
Accessories
Float Switch
Yes
Overview
Weight
41 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Width
9 Inches
Product Height
22.8 Inches
UPC
786102002516
Additional Model Numbers
WSP100, WSP100AA
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Running Amps
11.1
Power Cord Length
25 Feet
Pump
Gallons Per Minute
150 Gallons
Outlet Diameter
2"
Mechanical Seal Material
Ceramic Carbon
Housing Material
Stainless Steel
Impeller Material
Stainless Steel
Solids Handling Size
2 inch
Handles Solids
Yes
Maximum PSI
18
Total Head Lift
42 Feet
Submersible
Yes
Engine
Continuous Operation
Yes
Oil-Cooled
Yes
Shaft Seal
Ceramic Carbon
Horsepower
1 hp
Accessories
Float Switch
Yes
Overview
Weight
41 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Width
9 Inches
Product Height
22.8 Inches
UPC
786102002516
Additional Model Numbers
WSP100, WSP100AA
Product Q&A
(6)
+−
Search Product Q&A's
Answered by Jim, the Water Pump Expert
+−
Is the discharge threaded?
Douglas
from Florida
October 24, 2020
Answer
The discharge will have 2" NPT female threading.
Was this answer helpful?
Yes
0
No
0
+−
Will a 20-amp circuit handle this pump?
Michael F.
from Florida
May 08, 2018
Answer
While most manufacturers will list the running and starting amps for their pumps, they also recommend that all electrical connections be done in accordance with the National Electrical Code (NEC) and all state and local codes.
Was this answer helpful?
Yes
0
No
0
+−
Can this pump handle small debris in heavy rain and flooding with a 5 gallon basin?
Dave R.
from Alabama
February 07, 2017
Answer
That Honda WSP100 is a great pump but it's also a good sized pump and will definitely require a larger basin. That said, I would recommend a minimum 18" wide by 30" deep basin like the ones listed below. The larger the better as it will minimize the pump cycle rates.
TOPP Polyethylene Sewage Basin (18"x 30") w/ 4" Inlet Grommet Model: B24001
TOPP Structual Foam Sewage Basin (18"x 30") w/ 4" Inlet Grommet Model: E3-24001
TOPP Polyethylene Sewage Basin (18"x 30") w/ 4" Inlet Grommet Model: B24001
TOPP Structual Foam Sewage Basin (18"x 30") w/ 4" Inlet Grommet Model: E3-24001
Was this answer helpful?
Yes
0
No
0
+−
what temp is this pump rated for
Tim P
from California
October 08, 2013
Answer
Thank you for your interest in Water Pumps Direct. The Honda model WSP100AA is rated for a maximum temperature of 104 degrees(F).
Was this answer helpful?
Yes
1
No
0
+−
What is the measurement in inches from the bottom floor to the suction minimum for the WSP100-AAA?
Cullen Cooper
from California
May 21, 2013
Answer
On the Honda model WSP100, the actual opening or clearance from the bottom of the pump to the top of the pump inlet is exactly 2".
Was this answer helpful?
Yes
0
No
0
+−
Jose, I am wanting to use this pump (Honda WSP100AA - 150 gpm) as a sump pump for mostly rainwater to pump water from the safe side (inside) of a floodwall to protect a commercial building. The concrete floodwall will be approximately 6' from the outside of the builing leaving a sidewalk access around the building. Would you recommend this pump for this application. Thanks.
Jordan Horne
from Louisiana
March 07, 2013
Answer
Thank you for visiting Water Pumps Direct. The Honda WSP100AA is probably one of the best electric submersible pumps that you can buy. Since you are installing outdoors and there is the possibility of some small debris getting into the pump, the Honda or TSURUMI Trash pumps would be a good option for you. The main difference in the 2 brands are that the Honda pumps have a higher pumping capacity and an open bottom to the pump impeller and the Tsurumi pumps typically max out at 60 GPM and offers a bit more protection from larger debris getting into the pump inlet or impeller.
If you have additional questions, pleas don't hesitate to contact me.
If you have additional questions, pleas don't hesitate to contact me.
Was this answer helpful?
Yes
0
No
0
