Product Description
+−
Grade
Style
Run Watts
122,000
Rated Watts
Voltage
120/208 Three-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
122,000
Voltage
120/208 Three-Phase
Fuel
Natural Gas
Engine
Generac 6.8 L V-10
Features
Features
- SCAQMD Compliant
- Meets emissions requirements for sale in CA/MA
- Generac QT 130 Emergency Standby Generator
- Designed for small commercial buildings
- For 120/208 Volt Three-Phase applications
- Natural Gas (NG) Powered
- WILL NOT WORK with LP fuel source
- Solid State, Frequency Compensated Voltage Regulation
- Provides fast response to changing load conditions
- Allows for digital voltage regulation of +/- 1%
- 6.8L Generac V-10 Automotive-Style Engine
- Brushless Alternator - Less Than .25 % THD
- Improved frequency (HZ) regulation for cleaner power
- Digital Nexus™ Controller
- Two-Line, tri-lingual LCD display for ease of use
- Provides service & maintenance intervals
- Automatic Shutdown Safety Feature
- High coolant temp, low coolant, low oil pressure and overspeed
- Quiet-Test™ Mode
- Low-speed exercise mode for quieter weekly tests; 69 dB @ 23'
- Sound Attenuated, Acoustically Designed Aluminum Enclosure
- Corrosion-resistant material ideal for salty air conditions
- Mobile Link (Sold Separately)
- Easily check generator status via computer, tablet or smartphone
- Transfer Switch (Sold Separately)
- Customize your system based on your actual application
- 2-Year Limited Warranty
- ^Please Note - Requires Loading Dock, Forklift or Crane For Delivery^
Specifications
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
122000 Watts
Fuel Type
Natural Gas
NG Power Capacity
122000 Watts
NG Fuel Consumption @ 50% Load
927 ft³/hr
NG Fuel Consumption @ 100% Load
1786 ft³/hr
Rated Amps
423 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 Test (75 Run) dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (700 CCA)
Enclosure
Aluminum
Circuit Breaker Size
500 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac 6.8 L V-10
Starting System
12v Auto Start
CC
6800 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2970 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
2699 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
116 Inches
Product Width
37 Inches
Product Height
55 Inches
UPC
696471609769
Grade
Style
Run Watts
122,000
Rated Watts
Voltage
120/208 Three-Phase
Fuel
Engine
Grade
Emergency
Style
Standby (Liquid Cooled)
Run Watts
122,000
Voltage
120/208 Three-Phase
Fuel
Natural Gas
Engine
Generac 6.8 L V-10
Features
Features
- SCAQMD Compliant
- Meets emissions requirements for sale in CA/MA
- Generac QT 130 Emergency Standby Generator
- Designed for small commercial buildings
- For 120/208 Volt Three-Phase applications
- Natural Gas (NG) Powered
- WILL NOT WORK with LP fuel source
- Solid State, Frequency Compensated Voltage Regulation
- Provides fast response to changing load conditions
- Allows for digital voltage regulation of +/- 1%
- 6.8L Generac V-10 Automotive-Style Engine
- Brushless Alternator - Less Than .25 % THD
- Improved frequency (HZ) regulation for cleaner power
- Digital Nexus™ Controller
- Two-Line, tri-lingual LCD display for ease of use
- Provides service & maintenance intervals
- Automatic Shutdown Safety Feature
- High coolant temp, low coolant, low oil pressure and overspeed
- Quiet-Test™ Mode
- Low-speed exercise mode for quieter weekly tests; 69 dB @ 23'
- Sound Attenuated, Acoustically Designed Aluminum Enclosure
- Corrosion-resistant material ideal for salty air conditions
- Mobile Link (Sold Separately)
- Easily check generator status via computer, tablet or smartphone
- Transfer Switch (Sold Separately)
- Customize your system based on your actual application
- 2-Year Limited Warranty
- ^Please Note - Requires Loading Dock, Forklift or Crane For Delivery^
Specifications
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
122000 Watts
Fuel Type
Natural Gas
NG Power Capacity
122000 Watts
NG Fuel Consumption @ 50% Load
927 ft³/hr
NG Fuel Consumption @ 100% Load
1786 ft³/hr
Rated Amps
423 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 Test (75 Run) dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (700 CCA)
Enclosure
Aluminum
Circuit Breaker Size
500 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac 6.8 L V-10
Starting System
12v Auto Start
CC
6800 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2970 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
2699 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
116 Inches
Product Width
37 Inches
Product Height
55 Inches
UPC
696471609769
Product Specs
+−
Specifications
Product Specs
Voltage
120/208 Three-Phase
Frequency
60 Hertz
Alternator
Brushless
Auto Voltage Regulation
Yes
Rated Watts
122000 Watts
Fuel Type
Natural Gas
NG Power Capacity
122000 Watts
NG Fuel Consumption @ 50% Load
927 ft³/hr
NG Fuel Consumption @ 100% Load
1786 ft³/hr
Rated Amps
423 Amps
Decibel Rating @ 7m
Decibel Rating @ 7m
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69 Test (75 Run) dbA
Transfer Switch
Automatic (Not Included)
Battery
Not Included (700 CCA)
Enclosure
Aluminum
Circuit Breaker Size
500 Amps
Mounting Pad
Concrete (Not Included)
Cooling System
Liquid Cooled
UL Listed
Yes
Grade Type
Emergency
Engine
Engine Brand
Generac 6.8 L V-10
Starting System
12v Auto Start
CC
6800 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
2 Years
Engine RPM
2970 RPM
Low Oil Alert/Shutdown
Yes
Overview
Weight
2699 Pounds
Made in USA
Yes
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Style
Standby Generator
Product Length
116 Inches
Product Width
37 Inches
Product Height
55 Inches
UPC
696471609769
Reviews
+−
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Please share your insights with fellow shoppers.
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jared, the Generator Expert
+−
Where is the electric tie in on this generator, and what kind of clearance do we need if this product is gna be inside of a 6 foot brick fence
Rusty Willingham
from Texas
February 27, 2012
Answer
The installation drawing on the product page in the spec sheet shows where the electrical tie in is located (Stub Up Area) and the distance from a wall is minimum 5 feet but can vary based on your local code requirements.
Note 2 (Spec Sheet): ALLOW SUFFICIENT ROOM ON ALL SIDE OF THE GENERATOR FOR MAINTENANCE AND SERVICING. THIS UNIT MUST BE INSTALLED IN ACCORDANCE WITH CURRENT APPLICABLE NFPA37 AND NFPA 70 STANDARDS AS WELL AS ANY OTHER FEDERAL, STATE AND LOCAL CODES FOR MINIMUM DISTANCES FROM STRUCTURES.
Spec Sheet
Note 2 (Spec Sheet): ALLOW SUFFICIENT ROOM ON ALL SIDE OF THE GENERATOR FOR MAINTENANCE AND SERVICING. THIS UNIT MUST BE INSTALLED IN ACCORDANCE WITH CURRENT APPLICABLE NFPA37 AND NFPA 70 STANDARDS AS WELL AS ANY OTHER FEDERAL, STATE AND LOCAL CODES FOR MINIMUM DISTANCES FROM STRUCTURES.
Spec Sheet
