Dirty Hand Tools 3-Point Hitch Vertical/Horizontal Log Splitter (22 Tons Max Force)

Dirty Hand Tools 3-Point Hitch Vertical/Horizontal Log Splitter (22 Tons Max Force)
Our Price
Compare Prices
Shipping Info
Model: 100450
(Based on expert analysis, manufacturer ratings and customer reviews)
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews (3)
Write A Review
Product Discontinued
Sorry, this product is no longer available.
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • 3
    Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Force
22
Tons
Style
PTO Log Splitter
Type
Vertical/Horizontal Log Splitter
Log Length
25
Inches
Force
22 Tons
Style
PTO
Type
Vertical / Horizontal
Log Length
25 Inches
Features
Features
  • Split Wood In Horizontal Or Vertical Positions
  • Split smaller logs at comfortable waist height
  • Switch to vertical, save your back & roll large logs into place
  • Simply pull the pin and tilt up - then lock back into place
  • Use The Hydraulics You Already Own
  • Powered by the auxiliary outputs of your tractor
  • Connects to Cat 1 or Cat 2 tractor hydraulic system
  • 22-Ton Maximum Splitting Force
  • Easily split big logs up to 25" long
  • Splitting force determined by tractor PSI (don't exceed 3500 PSI)
  • Requires 3500 PSI to achieve 22 tons of splitting force
  • Cycle Time Of 9 To 15 Seconds
  • Cycle time is determined by the GPM produced by the tractor
  • Ideally tractor should produce 8 to 15 GPM at 1500 to 3500 PSI
  • 4" Diameter x 24" Stroke Cylinder
  • Auto return with adjustable detent
  • 8-Inch, Two-Way Heat Treated Steel Wedge
  • Beam has an 8" foot plate and removeable stripper plates
  • Built-in log cradle for added convenience and safety
  • Hydraulic Hoses NOT Included
  • Requires 1/2" diameter high pressure inlet and return hoses
  • Inlet hose length needs to be at least 41" long
  • Return hose length needs to be at least 59" long
Specifications
Hydraulics
Auto Return
Yes
Max Pump PSI
3500 PSI
Cylinder Diameter
4 Inches
Cylinder Length
24 Inches
Cycle Time
15 Seconds
Tonnage
22 Tons
Wedge
Wedge Material
Steel
Wedge Size
8 Inches
Wedge Style
2-way
Log Capacity
Max Log Length
25 Inches
Tractor Hitch
Tractor Hitch Style
3-Point
Accessories
Log Cradles
Included
Overview
Assembly Required
Yes
Weight
365 Pounds
Consumer Warranty
1 Year
Product Length
72.0 Inches
Product Width
22.0 Inches
Product Height
42.0 Inches
UPC
856206004119
Force
22
Tons
Style
PTO Log Splitter
Type
Vertical/Horizontal Log Splitter
Log Length
25
Inches
Force
22 Tons
Style
PTO
Type
Vertical / Horizontal
Log Length
25 Inches
Features
Features
  • Split Wood In Horizontal Or Vertical Positions
  • Split smaller logs at comfortable waist height
  • Switch to vertical, save your back & roll large logs into place
  • Simply pull the pin and tilt up - then lock back into place
  • Use The Hydraulics You Already Own
  • Powered by the auxiliary outputs of your tractor
  • Connects to Cat 1 or Cat 2 tractor hydraulic system
  • 22-Ton Maximum Splitting Force
  • Easily split big logs up to 25" long
  • Splitting force determined by tractor PSI (don't exceed 3500 PSI)
  • Requires 3500 PSI to achieve 22 tons of splitting force
  • Cycle Time Of 9 To 15 Seconds
  • Cycle time is determined by the GPM produced by the tractor
  • Ideally tractor should produce 8 to 15 GPM at 1500 to 3500 PSI
  • 4" Diameter x 24" Stroke Cylinder
  • Auto return with adjustable detent
  • 8-Inch, Two-Way Heat Treated Steel Wedge
  • Beam has an 8" foot plate and removeable stripper plates
  • Built-in log cradle for added convenience and safety
  • Hydraulic Hoses NOT Included
  • Requires 1/2" diameter high pressure inlet and return hoses
  • Inlet hose length needs to be at least 41" long
  • Return hose length needs to be at least 59" long
Specifications
Hydraulics
Auto Return
Yes
Max Pump PSI
3500 PSI
Cylinder Diameter
4 Inches
Cylinder Length
24 Inches
Cycle Time
15 Seconds
Tonnage
22 Tons
Wedge
Wedge Material
Steel
Wedge Size
8 Inches
Wedge Style
2-way
Log Capacity
Max Log Length
25 Inches
Tractor Hitch
Tractor Hitch Style
3-Point
Accessories
Log Cradles
Included
Overview
Assembly Required
Yes
Weight
365 Pounds
Consumer Warranty
1 Year
Product Length
72.0 Inches
Product Width
22.0 Inches
Product Height
42.0 Inches
UPC
856206004119
Product Specs
+
Specifications
Hydraulics
Auto Return
Yes
Max Pump PSI
3500 PSI
Cylinder Diameter
4 Inches
Cylinder Length
24 Inches
Cycle Time
15 Seconds
Tonnage
22 Tons
Wedge
Wedge Material
Steel
Wedge Size
8 Inches
Wedge Style
2-way
Log Capacity
Max Log Length
25 Inches
Tractor Hitch
Tractor Hitch Style
3-Point
Accessories
Log Cradles
Included
Overview
Assembly Required
Yes
Weight
365 Pounds
Consumer Warranty
1 Year
Product Length
72.0 Inches
Product Width
22.0 Inches
Product Height
42.0 Inches
UPC
856206004119
