Cummins Onan RV QD8000 - 8HDKAK-1046N - 8.0kW RV Generator (Diesel)

Cummins Onan RV QD8000 - 8HDKAK-1046N - 8.0kW RV Generator (Diesel)
Our Price
Compare Prices
Shipping Info
Model: RV QD 8000
(Based on expert analysis, manufacturer ratings and customer reviews)
$9,062.00
Factory-Direct
Ships in 3-4 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping
Free Lift Gate Service -
Add-Ons
Free Shipping$9,062.00Buy Now
Free Freight$9,062.00Visit Site
Factory-Direct
Ships in 3-4 Weeks
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii, Indiana, California or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Style
Run Watts
8,000
Rated Watts
Voltage
120 Single-Phase
Fuel
Engine
Grade
Recreational
Style
RV
Run Watts
8,000
Voltage
120 Single-Phase
Fuel
Diesel
Engine
Cummins Onan


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 8.0 kW Diesel Powered RV Generator (Model 1046)
  • Designed for dual AC Type A RVs (35A 2-Pole Breaker)
  • Runs two 15,000 BTU AC units w/ 3000 additional watts available
  • Cummins Onan 719cc Liquid-Cooled Diesel Engine
  • Automatic timed glow plugs for quick & easy starting
  • Elec. fuel pump w/ full oil & fuel filter (.49 Gal/h 1/2 Load)
  • Microprocessor Controlled
  • Self-diagnostic capability to simplify troubleshooting
  • High Quality, Pure Sine Wave Electrical Output
  • Digital voltage regulator prevents damaging spikes
  • Computer-Controlled Variable Speed Operation
  • Matches engine speed to load demand, minimizes noise levels
  • Sound-Attenuating Design w/ USDA Approved Spark-Arrestor Muffler
  • Lowers noise levels while providing cross-flow cooling
  • Three-Point, Fully Focalized Mounting System
  • Reduces vibration for quieter operation
  • Stationary exhaust pipe connection point for easy installation
  • Integrated Generator Set & Engine Control
  • Provides user friendly controls and safety features
  • 3 Year / 2000 Hour Warranty (Please See Warranty Sheet)
Specifications
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
HP
16.6 HP
CC
719 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
8000 Watts
Fuel Type
Diesel
Rated Amps
67 Amps
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
(66 @ 3M - Half Load) db(A)
Hour Meter
Yes
Min. Air Outlet - Bottom
7.3" x 12.7"
Min. Air Inlet - Front
6.4" x 20"
Grade Type
Recreational
Overview
Weight
420 Pounds
Product Style
RV Generator
Product Length
36.3 Inches
Product Width
23.6 Inches
Product Height
22.3 Inches
Consumer Warranty
3 Years
Grade
Style
Run Watts
8,000
Rated Watts
Voltage
120 Single-Phase
Fuel
Engine
Grade
Recreational
Style
RV
Run Watts
8,000
Voltage
120 Single-Phase
Fuel
Diesel
Engine
Cummins Onan


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 8.0 kW Diesel Powered RV Generator (Model 1046)
  • Designed for dual AC Type A RVs (35A 2-Pole Breaker)
  • Runs two 15,000 BTU AC units w/ 3000 additional watts available
  • Cummins Onan 719cc Liquid-Cooled Diesel Engine
  • Automatic timed glow plugs for quick & easy starting
  • Elec. fuel pump w/ full oil & fuel filter (.49 Gal/h 1/2 Load)
  • Microprocessor Controlled
  • Self-diagnostic capability to simplify troubleshooting
  • High Quality, Pure Sine Wave Electrical Output
  • Digital voltage regulator prevents damaging spikes
  • Computer-Controlled Variable Speed Operation
  • Matches engine speed to load demand, minimizes noise levels
  • Sound-Attenuating Design w/ USDA Approved Spark-Arrestor Muffler
  • Lowers noise levels while providing cross-flow cooling
  • Three-Point, Fully Focalized Mounting System
  • Reduces vibration for quieter operation
  • Stationary exhaust pipe connection point for easy installation
  • Integrated Generator Set & Engine Control
  • Provides user friendly controls and safety features
  • 3 Year / 2000 Hour Warranty (Please See Warranty Sheet)
Specifications
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
HP
16.6 HP
CC
719 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
8000 Watts
Fuel Type
Diesel
Rated Amps
67 Amps
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
(66 @ 3M - Half Load) db(A)
Hour Meter
Yes
Min. Air Outlet - Bottom
7.3" x 12.7"
Min. Air Inlet - Front
6.4" x 20"
Grade Type
Recreational
Overview
Weight
420 Pounds
Product Style
RV Generator
Product Length
36.3 Inches
Product Width
23.6 Inches
Product Height
22.3 Inches
Consumer Warranty
3 Years
Product Specs
+
Specifications
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
HP
16.6 HP
CC
719 CC
Consumer Engine Warranty
3 Years
Low Oil Alert/Shutdown
Yes
Product Specs
Voltage
120 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
8000 Watts
Fuel Type
Diesel
Rated Amps
67 Amps
Decibel Rating @ 7m ? Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
(66 @ 3M - Half Load) db(A)
Hour Meter
Yes
Min. Air Outlet - Bottom
7.3" x 12.7"
Min. Air Inlet - Front
6.4" x 20"
Grade Type
Recreational
Overview
Weight
420 Pounds
Product Style
RV Generator
Product Length
36.3 Inches
Product Width
23.6 Inches
Product Height
22.3 Inches
Consumer Warranty
3 Years
Reviews
+
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Product Q&A
(1)
+
Search Product Q&A's Answered by Jared, the Generator Expert
icon-social-fb1
+
Hello, I was curious if the Cummins Onan QD8000 could be wired to accept a standard 50Amp connection for our concession trailer. We are looking into replacing the portable 5K generator we have and mounting it on the front of the trailer on top of the tounge of the trailer. If it cant be wired for a 50A/4 prong plugin, can purchase a fuse box that would allow us to adapt our trailer to the generator? Any opinions on options would be appreciated. Thank you!
Keith Dalton
from North Dakota
March 30, 2014
Answer
This generator will not work with your concession trailer as the generators output is 120V only and cannot be converted to 240V per your 50A 4 wire information. This unit is designed for use in RV applications only and not recommended or designed for use in a concession trailer. We recommend you search for a true concession trailer generator that outputs 240V and comes with the appropriate warranty.
