Cummins Onan QG 5500 - 5.5HGJAE-6757 - 5500 Watt EVAP Commercial Mobile Generator (120/240V 30A)

Model:

A063B613

Write a Review
$4,687.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Factory-Direct
Ships in 16-20 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
synchrony card logo
$83 / Month
With our 82 months 10.99% APR*
82 fixed monthly payments required.
Free Shipping$4,687.00Buy Now
Free Freight$4,687.00Visit Site
Cummins Onan QG 5500 - 5.5HGJAE-6757 - 5500 Watt EVAP Commercial Mobile Generator (120/240V 30A)
Cummins Onan QG 5500 - 5.5HGJAE-6757 - 5500 Watt EVAP Commercial Mobile Generator (120/240V 30A)
Model: A063B613
$4,687.00
Features
Specifications
Reviews
Accessories
How-To Articles
Manuals
Share

Features

Grade

Professional

Style

RV

Run Watts

5,500 Rated Watts

Voltage

120/240 Single-Phase

Fuel

Gasoline

Engine

Cummins Onan



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
    For Additional Models - Please Call Us @ 1-800-800-3317
  • EVAP Model - Meets CARB Tier 3 & EPA Phase 3 Standards
  • 5.5 kW QG EVAP Commercial Mobile Generator (120/240V - 30A)
  • Quietest and lowest vibration generator set in its class
  • Designed for tough commercial applications - Runs (2) ACs
  • Cummins Onan 4-Cycle OHV V-Twin Engine (.6 Gal/H @ 1/2 Load)
  • Allows for start & run without AC output to conserve fuel
  • Microprocessor Controlled w/ Automatic Safety Shutdowns
  • Digital voltage regulatotion provides stabilty as loads change
  • Self-diagnostic capability to simplify troubleshooting
  • Low oil pressure, over/under speed, and overcurrent protection
  • Sound-Attenuating Enclosure w/ Thru Flow Cooling System
  • Lowers noise levels while providing cross-flow cooling
  • Integral Control Panel w/ Waterproof Remote Connector
  • Instant one-touch stop switch & Remote disable/continuous stop capability
  • 4-Point Mounting System w/ Coil Spring Vibration Isolators
  • Universal mounting tray allows for easy installation
  • Added Features -
  • Added Features - Auto Choke, Full-Flow Oil Filter & Long Life Fuel Filter
  • 2-Year Limited & 5-Year Drive Warranty (See Warranty Sheet)
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

A063B613
specs product image PID-15734
Product Specs
Voltage
120/240 Single-Phase
Frequency
60 Hertz
Alternator
Brush
Auto Voltage Regulation
Yes
Rated Watts
5500 Watts
Fuel Type
Gasoline
Rated Amps
22.9 Amps
Decibel Rating @ 3m
66
Hour Meter
Yes
Fuel Consumption
.35-.95 gallons/hr
Circuit Breaker Size
30 Amps
Grade Type
Professional
Engine
Engine Brand
Cummins Onan
Starting System
12-Volt Button Start
CC
653 CC
Consumer Engine Warranty
2 Years
Commercial Engine Warranty
3 Years
Engine RPM
2400 RPM
Low Oil Alert/Shutdown
Yes
Cast Iron Sleeve
Yes
Overview
Weight
290 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
Product Length
33.6 Inches
Product Style
RV Generator
Product Width
22.2 Inches
Product Height
16.7 Inches
Additional Model Numbers

5.5 HGJAE-6757, A063B613
