Briggs & Stratton™ Vanguard 896cc 32 Gross HP V-Twin OHV Electric Start Vertical Engine, Cyclonic AF, 1-1/8" x 4-1/2" Crankshaft
Model: 543777-0010-J1
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Share
  • Product Description
  • Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Features
Features
  • Model# 543777-0010-J1 - 1-1/8" x 4-1/2" Crankshaft, Tapped 7/16"-20, 1/4" Keyway
  • 3-Year Limited Warranty
  • Designed for Commercial Mowers, Chippers/Shredders, Concrete Trowels
  • Professional-Grade Vanguard™ 32 HP* Twin Cylinder Air-Cooled 4-Cycle Gas Engine
  • High-performance commercial engine rated in accordance with SAE J1995
  • BIG BLOCK™ (896cc) 90° V-Twin Overhead Valve (OHV) Technology
  • Low vibration, exceptional balance provides smooth power for extend valve life
  • Increased fuel economy and HP/Weight ratio while reducing engine emissions
  • Full-Pressure Lubrication w/ Centrally Located Oil Pump & Pickup + Oil Cooler
  • Centrally located pump for increased angle of operation and faster priming
  • Spin-On Oil Filter keeps oil cleaner from debris that can damage internal engine parts
  • Heavy-Duty Cylinder/Sump w/ Dura-Bore™ Cast Iron Cylinder Sleeves
  • Long engine life & improved oil control while reducing airborne intake debris
  • 5-Inch Cyclonic Multi-Stage Air Cleaner
  • Oversized, centrifugal design keeps the engine breathing in even the dustiest environments
  • Magnetron® Electronic Ignition & Industrial Grade Solenoid Shift Starter
  • Maintenance-free design, plus larger ignition coil for easy dependable starting
  • Innovative Debris Chopper Fan & Engineered Resin Blower Housing
  • Lower engine temperatures and less engine noise
  • Cooling Fin Inspection Panels
  • Makes it easy to inspect & clean
  • Additional Features:
  • 20A DC Alternator, Integrated Fuel-Pump, Remote Choke & Throttle Cables
  • Please Note - No Exhaust/Muffler or Fuel Tank Included
Specifications
Engine
Engine Series
B&S Vanguard
Engine Style
Vertical
Engine Type
4-Cycle OHV
Cylinders
2
Cooling System
Air
CC
896 CCs
HP
32 HP
Cylinder Bore Type
Cast Iron
Bore
3.42 Inches
Stroke
3.12 Inches
Compression Ratio
8:2:1
CARB
Yes
Systems
Charging System
20 Amps
Starting System
12-Volt Key Start
Ignition System
Magneto Spark
Lubrication
Lubrication
Pressurized
Oil Filter
Yes
Oil Capacity
82 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Float
Muffler
Not Included
Air Cleaner
Integrated Cyclonic Air Cleaner
Fuel Tank
Not Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
1-1/8 x 4-1/2 Inch
Crankshaft End Tapped Size
7/16-20
Crankshaft Keyway Width
1/4 Inch
Overview
Weight
125 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Power Type
Gas
UPC
047282072967
