Briggs & Stratton 12V332-0013-F1
Briggs & Stratton 12V332-0013-F1
Hover to zoom
1 Of 5
Briggs & Stratton Vanguard™ 205cc 6.5 Gross HP OHV Horizontal Engine, 3/4" x 2-7/16" Crankshaft
Model: 12V332-0013-F1
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$369.99
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States

Available Add-Ons
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+

Features
Features
  • Model 12V332-0013-F1 - 3/4" x 2-7/16" Keyway Crankshaft
  • Premium-Grade Vanguard™ 6.5 Gross HP* Single Cylinder Air-Cooled 4-Cycle Gas Engine
  • High-performance commercial engine rated in accordance with SAE J1995
  • Overhead Valve (OHV) Technology
  • More power, less fuel-use & lower emmisions; Runs cooler for longer engine life
  • Dura-Bore™ Cast Iron Cylinder Sleeve
  • Assures long engine life and improved oil control
  • Commercial-Style Float Carburetor w/ Sediment Filter
  • Proven-design for consitent starting, smoother operation & easy maintenance
  • Splash Lubrication System w/ Racing Designed Connecting Rod
  • Provides improved oil flow for better internal component protection & low oil sensor
  • High Capacity Dual-Clean™ Commercial Air Cleaner
  • Industrial pleated paper w/ foam pre-cleaner for demanding applicatins
  • Magnetron® Electronic Ignition
  • Maintenance-free design, plus larger ignition coil for easy dependable starting
  • TransportGuard™ System - Simultaneous Fuel/Ignition Shut-Off
  • Protects the engine from oil/fuel dilution during transport
  • Acoustically Designed Muffler System
  • Less noise keeps you working longer on the jobsite or in the yard
  • 3-Year Commercial Warranty
  • Model 12V332-0013-F1 Replaces Model 13L332-0036-F8
Specifications
Engine
Engine Series
B&S Vanguard
Engine Style
Horizontal
Engine Type
4-Cycle OHV
Cylinders
1
Cooling System
Air
Dry Weight
50 Lbs
CC
205 CCs
HP
6.5 HP
Cylinder Bore Type
Cast Iron
Bore
2.68 Inches
Stroke
2.20 Inches
Compression Ratio
8.3:1
Systems
Starting System
Recoil Only
Ignition System
Electronic Spark
Lubrication
Lubrication
Splash
Oil Filter
No
Oil Capacity
20 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Float
Muffler
Included
Air Cleaner
Dual Element
Fuel Tank Size
0.85 Gallons
Fuel Tank
Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
3/4 x 2-27/64 Inches
Crankshaft Type
Straight
Crankshaft Diameter
3/4"
Crankshaft Length
2-27/64"
Crankshaft End Tapped Size
5/16"-24
Crankshaft Keyway Width
3/16 Inches
PTO Height
4.17 Inches
Overview
Weight
50 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
UPC
047282758038

Features
Features
  • Model 12V332-0013-F1 - 3/4" x 2-7/16" Keyway Crankshaft
  • Premium-Grade Vanguard™ 6.5 Gross HP* Single Cylinder Air-Cooled 4-Cycle Gas Engine
  • High-performance commercial engine rated in accordance with SAE J1995
  • Overhead Valve (OHV) Technology
  • More power, less fuel-use & lower emmisions; Runs cooler for longer engine life
  • Dura-Bore™ Cast Iron Cylinder Sleeve
  • Assures long engine life and improved oil control
  • Commercial-Style Float Carburetor w/ Sediment Filter
  • Proven-design for consitent starting, smoother operation & easy maintenance
  • Splash Lubrication System w/ Racing Designed Connecting Rod
  • Provides improved oil flow for better internal component protection & low oil sensor
  • High Capacity Dual-Clean™ Commercial Air Cleaner
  • Industrial pleated paper w/ foam pre-cleaner for demanding applicatins
  • Magnetron® Electronic Ignition
  • Maintenance-free design, plus larger ignition coil for easy dependable starting
  • TransportGuard™ System - Simultaneous Fuel/Ignition Shut-Off
  • Protects the engine from oil/fuel dilution during transport
  • Acoustically Designed Muffler System
  • Less noise keeps you working longer on the jobsite or in the yard
  • 3-Year Commercial Warranty
  • Model 12V332-0013-F1 Replaces Model 13L332-0036-F8
Specifications
Engine
Engine Series
B&S Vanguard
Engine Style
Horizontal
Engine Type
4-Cycle OHV
Cylinders
1
Cooling System
Air
Dry Weight
50 Lbs
CC
205 CCs
HP
6.5 HP
Cylinder Bore Type
Cast Iron
Bore
2.68 Inches
Stroke
2.20 Inches
Compression Ratio
8.3:1
Systems
Starting System
Recoil Only
Ignition System
Electronic Spark
Lubrication
Lubrication
Splash
Oil Filter
No
Oil Capacity
20 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Float
Muffler
Included
Air Cleaner
Dual Element
Fuel Tank Size
0.85 Gallons
Fuel Tank
Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
3/4 x 2-27/64 Inches
Crankshaft Type
Straight
Crankshaft Diameter
3/4"
Crankshaft Length
2-27/64"
Crankshaft End Tapped Size
5/16"-24
Crankshaft Keyway Width
3/16 Inches
PTO Height
4.17 Inches
Overview
Weight
50 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
UPC
047282758038
Product Specs
+
Specifications
Engine
Engine Series
B&S Vanguard
Engine Style
Horizontal
Engine Type
4-Cycle OHV
Cylinders
1
Cooling System
Air
Dry Weight
50 Lbs
CC
205 CCs
HP
6.5 HP
Cylinder Bore Type
Cast Iron
Bore
2.68 Inches
Stroke
2.20 Inches
Compression Ratio
8.3:1
Systems
Starting System
Recoil Only
Ignition System
Electronic Spark
Lubrication
Lubrication
Splash
Oil Filter
No
Oil Capacity
20 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Float
Muffler
Included
Air Cleaner
Dual Element
Fuel Tank Size
0.85 Gallons
Fuel Tank
Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
3/4 x 2-27/64 Inches
Crankshaft Type
Straight
Crankshaft Diameter
3/4"
Crankshaft Length
2-27/64"
Crankshaft End Tapped Size
5/16"-24
Crankshaft Keyway Width
3/16 Inches
PTO Height
4.17 Inches
Overview
Weight
50 Pounds
Consumer Warranty
3 Years
Commercial Warranty
3 Years
UPC
047282758038
