Briggs & Stratton 125P05-0010-F1
Briggs & Stratton 125P05-0010-F1
Hover to zoom
1 Of 5

Briggs & Stratton Professional Series 190cc Electric Start Vertical Engine, 25mm x 3-5/32" Crankshaft, Tapped 3/8-24", 2 #605 Woodruff Keys & 1/4" Straight Keys

Model:

125P05-0010-F1

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Briggs & Stratton Professional Series 190cc Electric Start Vertical Engine, 25mm x 3-5/32
Briggs & Stratton Professional Series 190cc Electric Start Vertical Engine, 25mm x 3-5/32" Crankshaft, Tapped 3/8-24", 2 #605 Woodruff Keys & 1/4" Straight Keys
Model: 125P05-0010-F1
Product Discontinued
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Features

  • Replaces Engine Model #121S07-2062-F1
  • Model# 125P05-0010-F1 - 25mm x 3-5/32" Crankshaft, Tapped 3/8-24", (2) #605 Woodruff Keys & 1/4" Straight Keyway
  • For use on walk behind/push mowers
  • Briggs & Stratton Professional Series Single Cylinder Air-Cooled 4-Cycle Gas Engine
  • Produces 8.75 lbs/ft torque* - Power levels are stated gross torque per SAE J1995
  • Overhead Valve (OHV) Technology
  • More power, less fuel-use & lower emissions
  • Runs cooler for longer engine and valve life
  • Keeps the engine running cooler for maximum productivity
  • ReadyStart™ Starting System
  • No prime, no choke, no worries!
  • 12-volt electric start to save your shoulder with recoil backup
  • Dual-Sealing Air Cleaner
  • Improved debris resistance for a longer engine life
  • Acoustically-Engineered Muffler
  • Quiet operation and excellent tonal quality
  • Less Vibration
  • More user comfort and enhanced engine life
  • Float-Feed Carburetor & Mechanical Governor
  • Allows for fast fuel delivery for reliable starting and operation
  • Increases throttle response to maximize usable power for higher torque applications
  • Includes Fuel Tank
  • 2-Year Consumer & 90-Day Commercial Warranty
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

125P05-0010-F1
specs product image PID-97398
Engine
Engine Series
B&S Professional Series
Engine Style
Vertical
Engine Type
4-Cycle OHV
Cylinders
1
Cooling System
Air
Dry Weight
30 Lbs
CC
190 CCs
Max Torque
8.75 Lbs
Cylinder Bore Type
Aluminum
Bore
2.69 Inches
Stroke
2.04 Inches
CARB
Yes
Systems
Starting System
12-Volt w/ Recoil Backup
Ignition System
Electronic Spark
Lubrication
Lubrication
Splash
Oil Filter
No
Oil Capacity
20 oz
Intake/Exhaust
Fuel
Gas
Carburetor
Float
Muffler
Included
Air Cleaner
Dual Element
Fuel Tank Size
0.3 Gallons
Fuel Tank
Included
Crankshaft
Crankshaft Rotation Direction
Counterclockwise
Shaft Size
25mm x 3-5/32 Inches
Crankshaft Type
Straight
Crankshaft Diameter
25 mm
Crankshaft Length
3-5/32"
Crankshaft End Tapped Size
3/8"-24
Crankshaft Keyway Width
1/4 Inch
Overview
Weight
30 Pounds
Consumer Warranty
2 Years
Commercial Warranty
90 Days
Product Length
15.8 Inches
Product Width
13 Inches
Product Height
9.4 Inches
UPC
047282147948
