Barnes 2SEV1022L - 1 HP Cast Iron High-Volume Sewage Pump (Non-Automatic) (230V)
Model: 104982
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
Number of Reviews(1)
Write a Review
$1,202.00
Holiday Shipping Schedule
Holiday Schedule -
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Only 1 In-Stock
Ships Friday, Nov 27th
Shipping to60601
Shipping Details
  • Expedited Shipping Available - Shipping rates calculated at Checkout. Learn More
*We currently CANNOT ship this product to California or any destination outside of the United States
In-Stock Free Shipping$1,202.00Buy Now
In-Stock Free Shipping$1,202.00Visit Site
Direct Dollars
Earn up to 10% back in Direct Dollars
Share
  • Product Description
  • 1
    Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Sewage Pumps
GPH
8400
Gallons
Switch Type
None
Style
Sewage Pump
GPH
8400 Gallons
Switch Type
None
Features
Features
  • Barnes 2SEV1022L - 1 HP High-Volume Cast Iron Sewage Pump (Non-Automatic) (230V)
  • Designed for sewage removal in residential and light commercial applications
  • Requires float switch or controller for automatic operation
  • Enamel Coated Cast Iron Construction
  • Helps prevent corrosion in harsh sewage applications
  • 1 HP Permanent Split-Capacitor (PSC) Motor (230V)
  • Oil-filled, thermally protected, energy-efficient design, only draws 10.7 FLA
  • Cast Iron Vortex Impeller
  • Dynamically balanced design, can pass spherical solids up to 2"
  • Carbon/Ceramic/Buna-N Mechanical Seal
  • Assures maximum protection against pump failure
  • 416 Stainless Steel Shaft
  • Robust design helps increase life-span of pump
  • Oil-Lubricated, Upper & Lower Ball Bearings
  • Helps reduce vibration and provides quieter operation
  • 2" NPT (Female) Discharge
  • Will replace most pumps without any plumbing changes
  • 20-Foot, Quick-Disconnect Power Cord - Bare Lead
  • Pressure grommet for sealing and strain relief
  • 2-Year Limited Warranty
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
10.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Starting Amps
21.8
Pump
Mechanical Seal Material
Ceramic Carbon
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Total Head Lift
53 Feet
Float Type
No Switch
GPH @ 0 feet
8400
GPH @ 5 feet
8400
GPH @ 10 feet
8400
GPH @ 15 feet
8400
GPH @ 20 feet
8250
Discharge Port Size
2 Inch
Built-in check Valve
No
Submersible
Yes
Engine
Horsepower
1 hp
Overview
Weight
80 Pounds
Consumer Warranty
2 Years
Product Length
12.63 Inches
Product Width
9.75 Inches
Product Height
19.41 Inches
Style
Sewage Pumps
GPH
8400
Gallons
Switch Type
None
Style
Sewage Pump
GPH
8400 Gallons
Switch Type
None
Features
Features
  • Barnes 2SEV1022L - 1 HP High-Volume Cast Iron Sewage Pump (Non-Automatic) (230V)
  • Designed for sewage removal in residential and light commercial applications
  • Requires float switch or controller for automatic operation
  • Enamel Coated Cast Iron Construction
  • Helps prevent corrosion in harsh sewage applications
  • 1 HP Permanent Split-Capacitor (PSC) Motor (230V)
  • Oil-filled, thermally protected, energy-efficient design, only draws 10.7 FLA
  • Cast Iron Vortex Impeller
  • Dynamically balanced design, can pass spherical solids up to 2"
  • Carbon/Ceramic/Buna-N Mechanical Seal
  • Assures maximum protection against pump failure
  • 416 Stainless Steel Shaft
  • Robust design helps increase life-span of pump
  • Oil-Lubricated, Upper & Lower Ball Bearings
  • Helps reduce vibration and provides quieter operation
  • 2" NPT (Female) Discharge
  • Will replace most pumps without any plumbing changes
  • 20-Foot, Quick-Disconnect Power Cord - Bare Lead
  • Pressure grommet for sealing and strain relief
  • 2-Year Limited Warranty
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
10.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Starting Amps
21.8
Pump
Mechanical Seal Material
Ceramic Carbon
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Total Head Lift
53 Feet
Float Type
No Switch
GPH @ 0 feet
8400
GPH @ 5 feet
8400
GPH @ 10 feet
8400
GPH @ 15 feet
8400
GPH @ 20 feet
8250
Discharge Port Size
2 Inch
Built-in check Valve
No
Submersible
Yes
Engine
Horsepower
1 hp
Overview
Weight
80 Pounds
Consumer Warranty
2 Years
Product Length
12.63 Inches
Product Width
9.75 Inches
Product Height
19.41 Inches
Product Specs
+
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
230 Volt
Running Amps
10.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Starting Amps
21.8
Pump
Mechanical Seal Material
Ceramic Carbon
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Total Head Lift
53 Feet
Float Type
No Switch
GPH @ 0 feet
8400
GPH @ 5 feet
8400
GPH @ 10 feet
8400
GPH @ 15 feet
8400
GPH @ 20 feet
8250
Discharge Port Size
2 Inch
Built-in check Valve
No
Submersible
Yes
Engine
Horsepower
1 hp
Overview
Weight
80 Pounds
Consumer Warranty
2 Years
Product Length
12.63 Inches
Product Width
9.75 Inches
Product Height
19.41 Inches
