Atlas Copco G18 25-HP 132-Gallon AP Rotary Screw Air Compressor (208-230/460V 3-Phase)
Model: 8153335819
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$12,522.20
Was $13,258.80
Holiday Shipping Schedule
Holiday Schedule -
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 4-7 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
  • Lift Gate Service Available - $75.00 Service Charge Learn More
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Available Add-Ons
+$75.00
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Free Shipping$13,258.80$12,522.20Buy Now
Free Freight$12,522.20Visit Site
Direct Dollars
Earn up to 10% back in Direct Dollars
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Commercial
Style
Rotary Screw 3-Phase
CFM
99
CFM Rated @ 125 PSI
Tank Size
132
Gallons
Grade
Commercial
CFM
99 CFM Rated @ 125 PSI
Tank Size
132 Gallons
Features
Features
  • Latest Generation 25-HP Oil-Injected G Series
  • Ideal for small to medium businesses
  • Quiet performance doesn't require separate compressor space
  • Operates at ambient temperatures up to 115F (46C); top discharge lets it fit in small spaces against a wall or corner
  • Advanced BASE Electronic Controller
  • Icon based, easy to understand display for pressure settings, temperature readings, service warnings, & running hours
  • Allows outlet pressure setting directly from the controller; easily monitor outlet temperature
  • Robust & Efficient Belt-Driven Rotary Compression Element
  • Reduced noise levels and low vibration
  • Full sound enclosures which reduce the sound levels
  • Increases free air delivery by up to 3% compared to previous models
  • IP55 (TEFC) Motor
  • Meets or exceeds IEEE & NEMA premium efficiency standards with greased-for-life bearings
  • Load / No Load Control
  • Saves power to reduce energy cost and improves reliability
  • Automatically switches for high, low, and intermittent air consumption
  • Versatile
  • 100% continuous duty cycle for reliable operation
  • Meets ISO 9001, ISO 14001 & ISO 1217 which ensures a trouble-free air compressor
  • Spin-On Oil Separator & Oil Filter
  • Designed to be easily changed and maintained
  • 2-step separator system reduces oil consumption & protects lubrication quality
  • 132-Gallon ASME Air Tank
  • 1-inch NPT air outlet; integrates easily with your equipment
  • 1 Year Bumper-to-Bumper
Specifications
Engine
HP
25
Motor
Voltage
208-230/460 Volt AC
Phase
3-Phase
dBA
69
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Pump
CFM
99
CFM Rated @
125 PSI
Pump Material
Solid Cast Iron
Max PSI
125 PSI
Oil Sight Glass
Yes
Pump Type
Rotary
After Cooler
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
132 Gallons
Tank Outlet
1 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Filter
Oil Coalescing
Yes
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
1202 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
75 Inches
Product Width
33 Inches
Product Height
72 Inches
Power Type
Electric
Grade
Commercial
Style
Rotary Screw 3-Phase
CFM
99
CFM Rated @ 125 PSI
Tank Size
132
Gallons
Grade
Commercial
CFM
99 CFM Rated @ 125 PSI
Tank Size
132 Gallons
Features
Features
  • Latest Generation 25-HP Oil-Injected G Series
  • Ideal for small to medium businesses
  • Quiet performance doesn't require separate compressor space
  • Operates at ambient temperatures up to 115F (46C); top discharge lets it fit in small spaces against a wall or corner
  • Advanced BASE Electronic Controller
  • Icon based, easy to understand display for pressure settings, temperature readings, service warnings, & running hours
  • Allows outlet pressure setting directly from the controller; easily monitor outlet temperature
  • Robust & Efficient Belt-Driven Rotary Compression Element
  • Reduced noise levels and low vibration
  • Full sound enclosures which reduce the sound levels
  • Increases free air delivery by up to 3% compared to previous models
  • IP55 (TEFC) Motor
  • Meets or exceeds IEEE & NEMA premium efficiency standards with greased-for-life bearings
  • Load / No Load Control
  • Saves power to reduce energy cost and improves reliability
  • Automatically switches for high, low, and intermittent air consumption
  • Versatile
  • 100% continuous duty cycle for reliable operation
  • Meets ISO 9001, ISO 14001 & ISO 1217 which ensures a trouble-free air compressor
  • Spin-On Oil Separator & Oil Filter
  • Designed to be easily changed and maintained
  • 2-step separator system reduces oil consumption & protects lubrication quality
  • 132-Gallon ASME Air Tank
  • 1-inch NPT air outlet; integrates easily with your equipment
  • 1 Year Bumper-to-Bumper
Specifications
Engine
HP
25
Motor
Voltage
208-230/460 Volt AC
Phase
3-Phase
dBA
69
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Pump
CFM
99
CFM Rated @
125 PSI
Pump Material
Solid Cast Iron
Max PSI
125 PSI
Oil Sight Glass
Yes
Pump Type
Rotary
After Cooler
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
132 Gallons
Tank Outlet
1 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Filter
Oil Coalescing
Yes
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
1202 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
75 Inches
Product Width
33 Inches
Product Height
72 Inches
Power Type
Electric
Product Specs
+
Specifications
Engine
HP
25
Motor
Voltage
208-230/460 Volt AC
Phase
3-Phase
dBA
69
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Pump
CFM
99
CFM Rated @
125 PSI
Pump Material
Solid Cast Iron
Max PSI
125 PSI
Oil Sight Glass
Yes
Pump Type
Rotary
After Cooler
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
132 Gallons
Tank Outlet
1 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Filter
Oil Coalescing
Yes
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
1202 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
75 Inches
Product Width
33 Inches
Product Height
72 Inches
Power Type
Electric
