Reliance Controls XRC0603D - 60-Amp Utility/30-Amp (GFI) Gen Indoor Transfer Panel for sale.

Power Equipment Direct Offers Direct Discounts and a Tax-Free Guarantee on Reliance Controls XRC0603D.



Reliance Controls 60-Amp Utility/30-Amp (GFI) Gen Indoor Transfer Panel

Close
Reliance Controls Power Equipment and AccessoriesModel: XRC0603D
(Based on expert analysis, manufacturer ratings and customer reviews)
5.0 out of 55.0 out of 55.0 out of 55.0 out of 55.0 out of 5
1 Review
Share This Product
Plus 1 This Product
Tweet This Product
Pin It!
Factory DirectFactory Direct
Ships in 2-5 Business Days

Factory items ship direct from the manufacturer. Shipping times vary.
$279.99

StoreShippingPriceShop

$279.99
No Sales Tax*
(Except IL)
Buy

$279.99
No Sales Tax*
(Except IL)
Visit Site

$279.99
No Sales Tax*
(Except IL)
Visit Site
  • Features
  • Specs
  • 1
    Q&A
  • 1
    Reviews
  • Articles
  • Shipping
  • Accessories
Designed For Use With GFI-Equipped Portable Generators
Exclusive third-pole for the neutral that switches sequentially

Easily Switch Between A Portable Generator & Utility Power
Prevents sending 240V current to a 120V circuit

Prevents A Ground Fault
Prevents the circuit breakers on the generator from tripping

Useful Applications
Portable generators w/ GFCI protected outlets
Bonded neutral generators
Installations requiring a separately-derived system

Plenty of Branch Spaces
10 standard spaces
Up to 18 spaces with the use of tandem breakers
Product Specs
Frequency
60 Hertz
Rated Watts
7500 Watts
Enclosure
NEMA 1R
Neutral Type
Bonded
ATS Poles
3 Poles
Max Utility Input
60 Amps
Max Generator Input
30 Amps
Maximum Wattage
7500 Watts
Overview
Weight
26 Pounds
Product Length
21 Inches
Product Width
14.38 Inches
Product Height
3.94 Inches
Consumer Warranty
1 Year
UPC
815181015930
Model
XRC0603D

*Ask Mike about the Reliance Controls XRC0603D. Sorry, no repair questions:


*Name:


*State:


*Email:


 Receive Weekly How-To Tips & Specials


*Required Field Submit
  1 Question
Q: can this item be used also as a regular household subpanel when not being used as transfer switch? In other words, could I wire separate new circuit(s) within this panel, bearing in mind the amperage limitations?
by Ben C from South Carolina on January 23, 2014

A: Yes! The Reliance Controls XRC0603D is intended to function as a transfer panel / load center. This switch will support up to 10 standard circuit breakers under utility or generator power. This can be expanded to 18 circuits with the use of tandem circuit breakers. During a utility outage, only the circuits supported within this sub-panel will receive power.
by Mike, Product Expert
Reliance Controls XRC0603D Reviews & Ratings
1 Review  Sort by

Bill
Purchased from Power Equipment Direct
Purchased 1/15/13
REVIEWED
MAR.
16
2013
5 out of 55 out of 55 out of 55 out of 55 out of 5
High Quality
This high quality panel includes a interlock to switch the neutral. Good application when the code application for a separately derived system.
